76
Cooling function on systems with heating water buffer cylinder
Parameter Setting
"Cooling" Ó
"Cooling function 7100" "3"
"Cooling circuit 7101" "1" Heating circuit HC1
"2" Heating circuit HC2
"3" Heating circuit HC3
"4" Separate cooling circuit SKK
"Buffer cylinder" Ó
"Enable buffer cylinder/low loss header 7200" "1"
Note
Perform settings only in conjunction
with system schemes 1 and 2. Sys-
tem schemes 3 to 10 require a buffer
cylinder, which is preset.
Do not set with system scheme 11.
Room temperature sensor for separate cooling circuit
Parameter Setting
"Cooling" Ó
"Ranking room temp sensor separate cooling circuit 7106" "0" Connection F16
"1" Heating circuit HC1
"2" Heating circuit HC2
"3" Heating circuit HC3
"4" Do not adjust.
Cooling function in systems with a heating water/coolant buffer cylinder
Parameter Setting
"Cooling" Ó
"Cooling function 7100" "3"
"Buffer cylinder" Ó
"Enable buffer cylinder/low loss header 7200" "2"
"Heating circuit 1"/"Heating circuit 2"/"Heating circuit 3" Ó
"Cooling 2030"
and/or
"Cooling 3030"
and/or
"Cooling 4030"
"2"
Parameters for solar DHW heating
Parameters in conjunction with solar control module type SM1 Setting
"Solar" Ó
"Type solar control unit 7A00" "3"
Parameter C0xx See installation and service instruc-
tions for "Solar control module, type
SM1".
Commissioning, inspection, maintenance
Commissioning the system (cont.)
6199592
