Viessmann Vitocal 222-A - Page 101

101
Pos. Part
0001 220 l DHW cylinder with internal indirect coil
0002 DHW line
0003 Cold water line
0004 Pipe bend, DHW cylinder flow
0005 DHW cylinder flow line
0006 DHW cylinder return line
0007 DHW circulation pipe
0008 Sleeve
0009 Flange for protective magnesium anode with gasket
0010 High limit safety cut-out fixing
0011 Small parts (set)
0012 Air vent valve G ⅜
0013 Protective magnesium anode with flange and gasket
0014 Protective magnesium anode
0015 Shut-off valve G¾
0016 Drain and fill valve G ¾
0017 Locking cap G ¾ with retaining loop
0019 Spring clip 7 25 mm
0020 O-ring 7 20.63 x 2.62 mm (set)
0021 Gasket A 17 x 24 x 2.0 mm (set)
0022 Gasket 23 x 30 x 2.0 mm
0023 Flange gasket
Indoor unit parts lists
Indoor unit DHW cylinder (cont.)
5831412
Components
