29
1.
SW17
2.
Fig. 21
Type AWOT(-M)-E-AC only: Connecting the cooling circuit
For area cooling systems (e.g. underfloor heating cir-
cuit, chilled ceiling), a contact humidistat (accessories)
is required.
Installation sequence
Aligning the indoor unit
5831412
Installation
