Parameters for circulation pumps and other components
Heating circuit pump
Parameter Setting
"System definition" Ó
"System scheme 7000"
■
With heating circuit HC1 without mix-
er
or
■
With heating circuit HC2 with mixer
or
■
With heating circuit HC3 with mixer
DHW circulation pump
Parameter Setting
Extended menu Ó
"Time program DHW circulation" Set a time program.
Installation kit with mixer for heating circuit M2/HC2
Parameter Setting
"System definition" Ó
"Type of assembly kit 7044" "1"
"Internal hydraulics" Ó
"Rated output heating circuit pump HC2 734A" Set the required rated output in %.
Mixer extension kit for heating circuit M3/HC3
Parameter Setting
"System definition" Ó
"System scheme 7000" With heating circuit HC3
Note
Set rotary switch S1 in the extension
kit to "2": See "Mixer extension kit" in-
stallation instructions.
Remote control for heating/cooling circuit or Vitocomfort 200
Parameter Setting
"Heating circuit 1"/"Heating circuit 2"/"Heating circuit 3" Ó
"Remote control 2003"
or
"Remote control 3003"
or
"Remote control 4003"
"1"
Note
To assign a heating circuit, set the
code at the remote control:
See "Vitotrol" installation instructions.
Commissioning, inspection, maintenance
Commissioning the system (cont.)
