Viessmann VS 34 - Valve Parts List

31
Valve Parts List
Key
No.
Part No. Description
– 7384683
M
otor, Cam & Gear Kit, 3/4”
(includes Key Nos. 50-52)
50
á
Motor
51
á
Cam & Gear
52 7338111 Screw, #6-19 x 3.5 cm (2 req.)
53 7337474 Motor Mount
54 7030713 Switch
– 7331185
Drain Hose Adaptor Kit
(includes Key Nos. 55-59)
55
á
Clip, Drain
56
á
Drain Hose Adaptor
57
á
Hose Clamp
58
á
O-Ring, 15.9 x 20.6 mm
59
á
Flow Plug, 6.8 lpm
– 7129716 Seal Kit (includes Key Nos. 60-65)
60
á
O-Ring, 11.1 x 15.9 mm
61
á
O-Ring, 19.1 x 23.8 mm
62
á
O-Ring, 85.7 x 92.1 mm
63
á
Repl. Rotor Seal
64
á
O-Ring, 9.5 x 14.3 mm
65
á
Seal, Nozzle & Venturi
66 7082087 Wave Washer
67 7199232 Repl. Rotor & Disc
– 7342665
Drain Plug Kit, 3/4”
(includes Key Nos. 64, 68 & 69)
68
á
Plug, Drain Seal
69
á
Spring
70 7337563 Clip, 3/4”, pack of 4
71 7362110
Installation Adaptor, for 3/4” Valve,
1” BSPT, pack of 2, including 2
Clips, O-Rings & Silicone Grease
(See Key Nos. 70 & 72)
72
7390668
O-Ring, 23.8 x 30.2 mm, pack of 2,
including Silicone Grease
7337571 O-Ring, 23.8 x 30.2 mm, pack of 4
– 7113040
Turbine & Support Assembly,
including 2 O-Rings (See Key No.
72) & 1 ea. of Key Nos. 73 & 74
73
á
Turbine Support & Shaft
74
á
Turbine
Key
No.
Part No. Description
75 7082053 Valve Body
76 7081201 Retainer, Nozzle & Venturi
77 7342649 O-Ring, 6.4 x 9.5 mm, pack of 2
78 1202600 Nut - Ferrule
79
7268421
Nozzle & Venturi Assembly,
Model VS 34
(includes Key Nos. 80-89)
7238450
Nozzle & Venturi Assembly,
Models VS 74, VS 87 & VS 124
(includes Key Nos. 76, 77 & 80-89)
80 7081104 Housing, Nozzle & Venturi
81
7084607 Fill Flow Plug, .57 lpm, (Model VS 34)
1148800
Fill Flow Plug, 1.1 lpm,
(Models VS 74, VS 87 & VS 124)
82 0521829 Flow Plug, .38 lpm
83 7146043 Screen
84 7167659 Screen Support
85 7199729 Cap
–
7298549
Repl. Nozzle, Venturi & Gasket Kit,
Model VS 34
(includes Key Nos. 86-89)
7290957
Repl. Nozzle, Venturi & Gasket Kit,
Models VS 74, VS 87 & VS 124
(includes Key Nos. 86-89)
86
á
Cone Screen
87
á
Gasket, Nozzle & Venturi
88
á
Disc, Nozzle & Venturi, White
(Model VS 34)
á
Disc, Nozzle & Venturi, Red
(Models VS 74, VS 87 & VS 124)
89
á
O-Ring, 28.6 x 34.9 mm
90 7309803 Wire Harness, Position Switch
91 7337466 Valve Cover
92 7342657 Screw, #10-14 x 5 cm, pack of 5
93 7327631
Blending Bypass Valve, 3/4”,
Clip Style
¢
7328051
Blending Bypass Valve, 3/4”,
Threaded Ù
¢ Not illustrated
Ù Not included with softener
