12
R
echarge
Salt settings
Basic settings
Main menu
FIG. 26
MAIN MENU
During normal operation (status screens rolling), press
the softener’s OK / MENU button to display the Main
menu (See Figure 26). This menu and its subsidiary
screens are used to control these operations:
=Recharge (See Page 14)
=Salt settings
=Salt level (See Page 13)
=Low salt alarm (See Page 13)
=Basic settings
=Current time (See Page 14)
=Hardness (See Page 15)
=Iron level (See Page 15)
=Recharge time (See Page 15)
=Rolling screens (See Page 16)
=User preferences
=Language (See Page 16)
=Hardness units (See Page 17)
=System information
=Model information (See Page 18)
=Water available (See Page 18)
=Daily avg. water used (See Page 18)
=Water used today (See Page 18)
=Total water used (See Page 18)
=Current water flow (See Page 18)
=Days powered up (See Page 18)
=Last recharge (See Page 18)
=Total recharges (See Page 18)
=Advanced settings
=Cycle times
=Backwash time (See Page 19)
=2nd backwash (On/Off) (See Page 19)
=2nd backwash time (See Page 19)
=Fast rinse time (See Page 19)
=Special features
=Efficiency mode (See Page 20)
=Max. days between recharges (See Page 20)
=97% feature (See Page 20)
=Troubleshooting
=Diagnostics (See Page 21)
=Setup changes (See Page 22)
Programming the Water Softener
Efficiency mode
Max. days between rech...
97% feature
Special features
FIG. 27
Effieciency mode
97% feature
Special features
Max. days between
recharges
FIG. 28
LONG DISPLAY SCREEN MESSAGES
Most messages in the softener’s display screens are
short enough to be shown as a single line. Longer
messages will be truncated (See Figure 27 for an
example) until you highlight them.
One second after being highlighted, the viewing box
expands (See Figure 28) to show the entire message.
After three seconds the view resets (Figure 27).
