Viewpro Q30T - Gimbal Description

-3-
!
Please make sure that the motor is not stopped by any object during
the rotation, if the gimbal is blocked during rotation, please remove
the obstruction immediately.
[1]Gimbal fixed copper cylinder
[2] Damping ball
[3] Upper damping board
[4] Lower damping board
[5] YAW axis motorr
[6] Roll axis motor
[7] Pitch axis motor
[8] HD zoom camera
Gimbal Description
[4]
[2]
[5]
[1]
[
6]
[7]
[3]
[8]
