Viewpro Q30T - Connection of Control Box and Wiring Instruction

-6-
HDMI: micro HDMI OUTPUT
1080P 60fps default
SD card: max 32G, class10
FAT 32 or exFAT format
Connection of Control Box and Wiring Instruction
Z-3T controller box
PWM in
5V output
GND
TTL 115200/8/1/N
USER BOARD
RX
TX
GND
S.bus/Rx
Roll/Tx
Pitch
Yaw
Mode
Zoom
Focus
Pic/Rec
Multi
Av
