ViewSonic CD4225 9
AUDIO-IN R/L
To input audio signals from external equipment such as a VCR or DVD player.
HDMI
To input digital RGB signals from a computer.
* This connector does not support analog input. Audio is supported via HDMI.
DVI-IN
To input digital RGB signals from a computer.
*This connector does not support audio input. The audio signal should be connected to the LINE-IN
jack.
DVI-OUT
To output digital RGB signals from DVI-IN to another monitor.
VGA IN (mini D-Sub 15 pin)
To input analog RGB signals from a computer or other RGB equipment.
VGA OUT (mini D-Sub 15 pin)
To output signals from VGA IN.
RS232C-IN (mini D-Sub 9 pin)
Connects to the RS-232 output connector of a computer, or the RS232C-OUT connector of a multi-
connected CD4225 monitor.
RS232C-OUT (mini D-Sub 9 pin)
Connects to the RS232C-IN connector of another CD4225 monitor.
Y Pb Pr IN
Connects to equipment such as a DVD player, HDTV device or Laser disc player.
Y Pb Pr OUT
To output signals from Y Pb Pr IN.
Main power switch
Turns the LCD monitor’s main power on or off.
AC-IN (100-240VAC, 5.5A)
Connects to the supplied power cord.
AC-OUT (100-240VAC, 5.5A)
Outputs AC power to another CD4225 monitor.
