Connecting a Personal Computer
Connecting your computer to your LCD monitor will enable you to display your computer's screen
image. Some video cards may not display an image correctly.
Connect the LCD Monitor to a Personal Computer
• To connect the VGA IN connector (mini D-sub 15 pin) on the LCD monitor, use a PC - Video RGB
signal cable (mini D-sub 15 pin to mini D-sub 15 pin).
• When connecting one or more LCD monitors, use the VGA OUT connector (mini D-sub 15 pin).
• The LINE-IN jack can be used for audio input.
• The SPEAKERS jack outputs sound from the selected Audio input.
To audio output
To analog RGB output
LCD monitor (second monitor)
* Cables are not supplied
To Next Page
