36
• Press ENTER, and then the or button to turn this function on or off.
Advanced
• Press the ENTER button to display the diagnostic information of the LCD monitor:
• Reset User Default: (1)!If activated, all OSD settings (except the Language setting) will be
restored to the factory settings. (2)!Press the ENTER button to activate the reset.
• OSD Info Box: Disable or enable OSD information.
• Thermal: Displays the current temperature inside the LCD monitor.
• Ambient: Displays the current ambient brightness around the LCD monitor.
• 5V Detect: Displays the current 5V voltage detection result.
• 12V Detect: Displays the current 12V voltage detection result.
• Operating Time: Displays the time elapsed since the LCD monitor was last turned on. D=Day,
H=Hour.
Thermal + 38 C
Ambient 368Lux
5V Detect 4.8V
12V Detect 11.8V
Operating Time 2D 23H
FW Version
Input Source
Setting
:Move
:Enter
:Exit
Enter
Exit
status
Restore User Default
OSD Info Box ON
To Next Page
