ViewSonic E55 User Manual

ViewSonic E55/E55B
7
Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OSD controls. The OSD
controls are explained at the top of the next page and are defined in “Main Menu Controls” on
page 9.
1
2
ViewSonic
MAIN MENU 1
EXIT :
SELECT
:
CONTRAST/BRIGHTNESS
ZOOM
H. POSITION / SIZE
V.
POSITION / SIZE
PINCUSHIO / PIN BALANCE
TRAPEZOID / PARALLEL
TIL
T
1
2
1
2
Main Menu
With OSD controls
Front Control Panel
shown below in detail
• Scrolls through menu options and
adjusts the displayed control.
• Displays the control screen for the
highlighted control.
• Also toggles between two controls on
some screens.
Power LED
Green = ON
Orange = Power Saving
Power
On/Off
Displays the Main Menu or exits the
control screen and saves adjustments.
