4.0 INTERFACE REQUIREMENT
4.1 Power input requirements
4.1.1 Operating voltage range:90 ~ 264VAC , 50/60 ± 3Hz
4.1.2 Input Current at 120V
a. Operating :2.0Amps RMS maximum
b. Inrush current :40 Amps peak maximum
4.1.3 Input Current at 240V
a. Operating :1.0 Amps RMS maximum
b. Inrush current :60 Amps peak maximum
4.1.4 Power management
MODE H-SYNC V-SYNC POWER INDICATOR
NORMAL YES YES ≦115W GREEN
Power saving NO YES ≦10W AMBER
Power saving YES NO ≦10W AMBER
Power saving NO NO ≦2W AMBER
4.2 Signal Input Requirement
4.2.1 Connector
a. 15 pin D-sub high-density connector for video and sync signals. (See Appendix A for pin assignment)
b. Cable length ︰1.8meters with ivory color.
4.2.2 Video Signals
a. Red, Green, Blue channels analog input.
b. Amplitude :0.7Vp-p/1Vp-p(OSD SLECT)
c. Polarity :Positive bright, 0.7Vp-p for full intensity and 0Vp-p for black.
d. Impedance :75 ohms±5%
4.2.3 Sync signal
a. Separate H and V sync or composite H+V sync.
b. Voltage level ︰Standard TTL
c. Input impedance ︰2KΩ
d. Polarity ︰Negative or Positive.
