1.0 SCOPE
This specification defines the performance of C110 SAW 21inch digital OSD controlled color monitor. This color monitor
is designed to accept timing signals within horizontal frequency ranging from 30KHz to 110KHz and vertical frequency
ranging from 50Hz to 180Hz. It is compatible with VGA, super VGA, and enhanced VESA standards for 640x480,
800x600, 1024x768, 1280x1024 and 1600x1200 non-interlaced display. All parameters within this specification must be
met at any line voltage, line frequency and temperature within the limits specified in this document.
2.0 GENERAL PERFORMANCE
2.1 Display mode & resolution
15 settings of display parameters are pre-adjusted and stored in memory for user’s convenience, another 10 settings
of memory are available for user to adjust and store parameters.
PRESET MODE FREQUENCY SYNC POLARITY
RESOLUTION HOR. VER. HOR. VER.
640x400 31.47KHz 70Hz - +
640x480 31.47KHz 60Hz - -
640x480 43.269KHz 85Hz - -
800x600 46.875KHz 75Hz + +
800x600 53.674KHz 85.01Hz + +
1024x768 60.24KHz 74.927Hz + +
1024x768 60.023KHz 75.029Hz + +
1024x768 68.677KHz 84.997Hz + +
1280x1024 79.976KHz 75.025Hz + +
1280x1024 91.146KHz 85.024Hz + +
1600x1200 93.750KHz 60.00Hz + +
832x624 49.714KHz 75.534Hz - -
1152x870 68.681KHz 75.061Hz - -
1600x1200 106.25KHz 85Hz + +
2.2 Scanning Frequency ： 30KHz to 110KHz for Horizontal
50Hz to 180Hz for Vertical
2.3 Display Size ： 390mm x 290mm for all modes
2.4 Display Brightness ： 30±3 FL at center of screen (Full white pattern)
33±3 FL at center of screen (20% window block pattern)
(Brightness set to 50% & Contrast set to 100%)
2.5 White Balance ： CIE coordinates
9300K
x = 0.283±0.015
y = 0.297±0.015
6500K
x = 0.313±0.015
y = 0.329±0.015
5000K
x = 0.346±0.015
y = 0.359±0.015
2.6 Power Input Range ： AC 90 to 264V, 50/60Hz ± 3Hz
2.7 Power Consumption ︰ 115 Watts max.
2.8 Degauss ： both Automatic and Manual
