ViewSonic G220f-1 - Adjusting Procedure

A"
""
"GENERAL"
""
"
B"
""
"INSTRUMENT ALIGNMENT"
""
"
1"Deflection Presets"
2"Power Supply Alignment"
3"Size & Geometry Adjustment"
4"Video Alignment / function memory recall"
5"Focus adjustment"
C"
""
"PCB DEFINED"
""
"
D"
""
"FIXTURE FUNCTION DESCRIPTION"
""
"
ViewSonic Corporation
41
Confidential – Do Not Copy
7.
ADJUSTING PROCEDURE
1. All specification must be met over line voltage range of 90vac to 264VAC 50Hz / 60Hz, unless otherwise specified"
2. Operating temperature range is 0# to 40# with a relative humidity of 10% or less to 90%"
3. The monitor must be operational in a usable state within 30 minutes after turn-on"
4. All signal levels are measured assuming termination at the monitor’s input jacks or in its characteristic impedance"
5. An ambient lighting level of 400 to 600 Lux is assumed when setting brightness for raster extinction threshold"
6. All purity related specifications must be met without external degaussing"
7. All controls must have excess range$no control may be left at an end stop when proper alignment is completed%"
8. The monitor is not required to meet specs during the following but must tolerate, without damage to the CRT or
circuits, any sequence or combination of power on and off, signal on and off, unplugging of power or signal, erratic,
wrong frequency or noisy inputs while at any possible settings of user accessible controls likewise, the monitor
should survive extended periods of operation with line voltage reduced below the specified minimum.
9. An isolation transformer should be used when performing alignment and tests"Portions of the power supply board
are hot ground"The remaining boards are cold ground"
10. Discharge of CRT anode should be done only to CRT ground strap"
11. Geometric measurements are assumed to be made along a straight surface with a flat rule or template"
