ViewSonic G220f-1 - Table of Contents

ViewSonic Corporation
iii
TABLE OF CONTENTS
1.
PRECAUTIONS AND NOTICES...............................................................................1
2.
SPECIFICATIONS.....................................................................................................4
3.
FRONT PANEL FUNCTION CONTROL DESCRIPTION....................................16
4.
CIRCUIT DESCRIPTION........................................................................................19
5.
BLOCK DIAGRAM .................................................................................................24
6.
SCHEMATIC DIAGRAMS.......................................................................................25
7.
ADJUSTING PROCEDURE....................................................................................41
8.
TROUBLE SHOOTING FLOW CHART..................................................................51
9.
EXPLODED DIAGRAM AND SPARE PARTS LIST...............................................57
Confidential – Do Not Copy
10. DISASSEMBLY INSTRUTCTION............................................................................59
11. PCB LAYOUT DIAGRAMS......................................................................................61
12. RECOMMEND SPARE PARTS LIST.......................................................................63
G220f-1_G220fB-1
