3. Fixture adjust procedure"
Initial data
G90f2 dat
Pull / adjust /-
( 255 ~ 0)
Save color to 9300K
Save color to 6500K
Save color to 5000K
Save geometry
All mode
adjust finish?
Save all preset mode
Yes
No
Yes
Initial OK?
No
Get mode data
Change other
mode
ViewSonic Corporation
50
Confidential – Do Not Copy
4. Fixture Connect"
a. Fixture adjustment"
PC
Pattern
Generator
Monitor
Signal cable
RS232
H/V SYNC
Video
Output :
Input :
H/V SYNC
Video
Initial dat
a
Adjustment
d
Initial data /
Adjust data
Write to monito
r
Read E
2
PROM data
form monito
r
Signal cable
