19" (18.0" VIEWABLE) PROFESSIONAL COLOR MONITOR WITH PERFECTFLAT
®
CRT
CRT Type 19" (18.0" viewable) 90˚ deflection
Pitch 0.25mm center - 0.27mm corner aperture grille
Phosphor RGB medium-short persistance B22
Glass Surface Tint (TM=40%), ARAG
®
screen treatment
INPUT SIGNAL Video RGB Analog (75 ohms, 0.70 Vp-p,)
Sync H/V separate (TTL) composite, sync-on-green
Frequency F
h
:30-117kHz, F
v
:50-180Hz
COMPATIBILITY PC PC compatible from VGA up to 1920 x 1440
Mac
®1
Power Mac
™
compatible from 640 x 480 up to 1920 x 1440
Other Most workstations
2
CONNECTOR Signal 15-pin mini D-sub (detached) BNC x 5 (RGBHV)
3
Power 3-pin plug (IEC320)
POWER Voltage
AC 100-240V (auto switch) 50-60(+/-3)Hz
Consumption 130W (typ)
USER CONTROLS Basic Power, ON/OFF, 1, down, up, 2
OnView
®
Contrast, brightness, H/V-position, H/V-size, pincushion,
trapazoid, pin balance, zoom, parallelogram, hooking
(top and bottom), degauss, purity, V-linearity center,
V-linearity edge, moire, ViewMatch
®
color, purity, tilt,
H/V convergence, ViewMeter
®
, OSD control, H/V focus,
OSD language select, input select, data recall
VIDEO INPUT Bandwidth 300MHz (typ)
MISCONVERGENCE
0.25mm (max at center), 0.35mm (max at corner)
DISPLAY AREA Factory Setting 353mm (H) x 265mm (V)
Maximum Scan 364mm (H) x 275mm (V)
(Dependent upon signal timing used)
OPERATING Temperature 32˚F to 104˚F (0˚C to 40˚C)
CONDITION Humidity 5% – 95% (non-condensation)
DIMENSIONS Physical 470mm (W) x 470mm (H) x 477mm (D)
18.5" (W) x 18.5" (H) x 18.8" (D)
WEIGHT Net 25.0KG (55.0lb)
OTHER DDC1, DDC2B, GTF
REGULATIONS UL, CSA, FCC-B, DHHS, E
NERGY STAR
®
,
TCO ’99, MPR-II,
Energy 2000, CE, CB, VCCI, C-TICK, NEMKO, PSB,
DEMKO, SEMKO, FIMKO, NOM, TUV/GS, PCBC,
TUV/ERGO, TUV/S-MARK, ISO 9241-3
POWER MANAGEMENT Meets E
NERGY STAR
®
,
VESA
®
DPMS, TCO ’99 and
Energy 2000 standards
WARRANTY Three year limited warranty on CRT, parts and labor.
48 hour Express Exchange
®
service option available.
• ARAG
®
screen treatment
This specially formulated anti-reflection,
anti-glare screen treatment uses a multi-layer
process to refract unwanted light away
from the user while maintaining the highest
quality image.
• OnView
®
controls including ViewMatch
®
All screen adjustments are made via an on-screen
menu using simple controls. ViewMatch allows
the user to adjust color temperature and individ-
ual color intensity for screen-to-print matching.
• TCO ’99 and Energy 2000 certified
This monitor complies with the
world's strictest standards of low
radiation, safety, ergonomics,
recycling and power manage-
ment while saving costs through
automatic power saving modes.
•
Fully supports the Microsoft
®
Windows
®
auto-installation standard for easy, trouble-free
configuration and setup.
• PC and Mac
®
compatible
• Three year limited warranty
24/7 free technical and customer support.
1
Requires Mac cable adapter for older model.
2
Requires optional adapter. Copyright © 2000 ViewSonic Corporation. All rights reserved. Corporate names and trademarks stated herein are property of their respective companies.
Specifications subject to changes without notice. As an E
NERGY STAR
®
partner, ViewSonic has determined that this product meets the E
NERGY STAR
®
guidelines for energy efficiency. Microsoft, Windows, Windows NT and the Windows logo
are the registered trademarks of Microsoft Corporation in the United States and other countries.
VSP95f_10/00_20k_rev1
VS-2113
381 Brea Canyon Road, Walnut, CA 91789
Phone (800) 888-8583 • (909) 869-7976
Fax (909) 468-1202 • Internet: www.ViewSonic.com
ViewSonic
®
Professional Series
P95f Monitor
ViewSonic Corporation's QMS\ EMS has been registered
to ISO 9001 & ISO 14001 by the British Standards Institution.
