Mini Type B USB
(USB Display)
www.ViewSonic.com
ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
DISPLAY Type 0.55" Digital Micromirror Device (DLP™)
Resolution XGA 1024x768 (native)
Lens 1.6x Manual optical zoom / manual optical focus
Keystone Vertical digital keystone correction (+/- 40º)
Size 30 – 300 in. / 0.7 – 7.6 m (diagonal)
Throw Distance 3.9 – 32.8 ft. / 1.2 – 10.0 m
Throw Ratio 1.39~2.23:1
Lamp 330 watt
Lamp Life 2500 / 3500 hours* (Normal / Eco-mode)
Brightness 4000 Lumens
Contrast Ratio 15,000:1 (w/ DynamicEco
™
)
Aspect Ratio 4:3 (native)
Color Depth 30 bits, 1.07B Color (10+10+10)
Color Wheel 6-seg RGBCYW / 7200rpm
INPUT SIGNAL Computer and Video NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60),
SECAM (B, D, G, K, K1, L), SD 480i and 576i, ED 480p and
576p, HD 720p, 1080i, 1080p
Frequency Fh: 31–100KHz, Fv: 24–120Hz
COMPATIBILITY PC VGA to 1600x1200 UXGA
Mac
®
Up to UXGA (may require MAC adaptor)
CONNECTOR RGB Input 15-pin mini D-sub (x2)
RGB Output 15-pin mini D-sub
Digital Input HDMI
Component Input 15-pin mini D-sub (x2, shared with RGB)
Composite Input RCA jack
S-Video Input 4-pin mini-DIN
Audio Input 3.5mm mini jack (x2)
Microphone Input 3.5mm mini jack (shared with Audio 2)
Audio Output 3.5mm mini jack
Control RS-232 (DB-9)
LAN RJ45
USB Type A (card reader and wireless dongle)
Type B (mouse control and service)
Mini Type B (USB display)
DC 12V Trigger 3.5mm plug 12V/1A
AUDIO Speaker 16-watt (x1)
POWER Voltage 100~240VAC (Auto Switching), 50/60Hz (universal)
Consumption 350W (typ) / <0.5W (stand-by mode)
CONTROLS Basic Power, keystone/arrow keys, left, menu/exit, right, source, enter
OSD Picture, Video/Audio, Setting, Option, Language, Information
(See user guide for full OSD functionality)
OPERATING Temperature 32ºF–104ºF (0ºC–40ºC)
CONDITIONS Humidity 10%–90% (non-condensing)
Altitude 0~6,000 ft (1,800m), operational up to 10,000 ft (3,048m)
NOISE LEVEL Normal / Eco-mode 34dB / 32dB
DIMENSIONS Physical 13.2 x 5.1 x 10.4 in. / 335 x 128.3 x 265 mm
(W x H x D) Packaging 15.0 x 13.5 x 9.5 in. / 383 x 342 x 242 mm
WEIGHT Net 6.7 lbs. / 3.0 kg
Gross 11.2 lbs. / 5.1 kg
REGULATIONS CB, UL/cUL, FCC-B, NOM, KC, REACH, ErP, SVHC
UL-Argentina, PSB, C-tick, SASO, CE, GOST-R,
CCC, RoHS, WEEE, UkrSEPRO
PJD7333
PJD7333 projector, power cable, VGA cable, remote control with batteries, carrying case,
Quick Start Guide, ViewSonic Wizard DVD (with User Guide).
What's in the box?
Optional Accessories
Replacement Lamp ........................................RLC-081
3D Active Shutter Glasses ......................... PGD-series
Audio In / Out
AC Power
Monitor Out
S-Video/Video Inputs
Type B USB
(Mouse Control &
Service)
RGB/Component
Video Inputs
3D Blu-ray Ready HDMI
HDMI delivers the highest picture and sound quality without
degradation. Equipped with the latest HDMI, ViewSonic's
PJD7333 projector can display 3D images directly from 3D
Blu-ray
®
players—perfect for connecting to any HDMI-enabled
devices such as PCs, laptops, tablets, and media players.
Focus Ring
Control Panel
IR Remote Sensor
Projection Lens
Quick elevation button
Kensington
®
Lock Slot
Projection Distance
Screen Size (4:3)
Diagonal
Feet
3.7 - 6.0
7.4 - 11.9
11.1 - 17.8
13.9 - 22.3
18.5 - 29.7
23.2 - 37.1
27.8 - 44.6
Inches
40
80
120
150
200
250
300
Meters
1.1 - 1.8
2.3 - 3.6
3.4 - 5.4
4.2 - 6.8
5.6 - 9.0
7.0 - 11.3
8.4 - 13.6
Meters
1.0
2.0
3.0
3.8
5.1
6.4
7.6
Zoom Ring
Type A USB
(For card reader and
wireless dongle)
LAN RJ45
HDMI
Superior Color Performance
BrilliantColor
™
technology provides multi-color processing to
produce stunning, vibrant colors. Unlike other technologies that
use just 3 primary colors to produce the image (such as LCD),
the PJD7333 uses up to 6 separate colors. The sophisticated
6-segment color wheel enhances the yellow color performance
that is key to accurate and vivid color reproduction.
RS-232
High Brightness
Networkable XGA Projector
DC 12V Out
DICOM SIM Mode Support
With the DICOM (Digital Imaging and Communications in Medicine) SIM mode,
ViewSonic’s PJD7333 is able to simulate and display multiple screens of X-rays,
sonograms, and nuclear magnetic resonance (NMR) images. Whether for medical
or educational presentations, the PJD7333 delivers the most
accurate and detailed images.
Wide Optical Zoom Lens
Equipped with a 1.6x optical zoom lens, the
PJD7333 provides mounting flexibility with a
wider throw distance range. This zoom lens also
enables the projector to project images up to 50%
larger than a conventional projector equipped with
a 1.1x lens.
15,000 : 1
