ViewSonic va1616w-8 - Factory Defaults and Function Testing

- 26 –
5.4 Factory Defaults
Item Defaults Item Defaults
Contrast 70% Input Priority N/A
Brightness 100% Resolution Notice On
Color Temperature 6500K Volume N/A
Sharpness 100% Balance N/A
OSD H. Position 50% Treble N/A
OSD V. Position 50% Bass N/A
OSD Time Out 15 720x400 / 640x400 720x400
OSD Background On DCR ON : For Region code =
E/G/P/A/S/K/U/J units only
OFF: For Region code = M
units only
5.5 Function Test
1 Product: 16” LCD Monitor
2 Test Equipment: Color Video Signal & Pattern (or PC with SXGA resolution)
3 Test Condition: Before function test and alignment, each LCD Monitor should be
warmed up for at least 30 minutes with the following conditions:
(a)In room temperature,
(b) With full-white screen, RGB, and Black
(c) With cycled display modes,
640*480 (H=43.27kHz, V=75Hz)
800*600 (H=53.7kHz, V=75Hz)
1024*768 (H=68.67kHz, V=60Hz)
1280*1024 (H=79.97kHz, V=60Hz)
1366*768 (H=55.9kHz, V=60Hz)
4 Test Display Modes & Pattern
Compatible Modes
Item Timing Analog
1 640 x 480 @ 60Hz, 31.5kHz
Yes
2 640 x 480 @ 75Hz, 31.5kHz
Yes
3 720 x 400 @ 70Hz, 31.5kHz
Yes
4 800 x 600 @ 56Hz, 35.1kHz
Yes
5 800 x 600 @ 60Hz, 37.9kHz
Yes
6 800 x 600 @ 72Hz, 48.1kHz
Yes
7 800 x 600 @ 75Hz, 46.9kHz
Yes
8 1024 x 768 @ 60Hz, 48.4kHz
Yes
9 1024 x 768 @ 70Hz, 56.5kHz
Yes
10 1024 x 768 @ 72Hz, 58.1kHz
Yes
11 1024 x 768 @ 75Hz, 60.0kHz
Yes
12 1280 x 1024 @ 60Hz, 48.4kHz
Yes
13 1366 x 768 @ 60Hz, 60.0kHz
Yes
