ViewSonic VA2033-LED User Manual

ViewSonic VA2033-LED/VA2033a-LED 9
Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OSD controls which display
on the screen. The OSD controls are explained at the top of the next page and are defined in
“Main Menu Controls” on page 11.
VA2033a-LED
Scrolls through menu
options and adjusts
the displayed control.
Brightness (T) /
Contrast (S)
Displays the control screen for
the highlighted control.
Also toggles between two
controls on some screens.
Also a shortcut to Auto Image
Adjust.
Power light
Blue = ON
Orange = Power Saving
Displays the
Main Menu or
exits the control
screen and
saves
adjustments.
Standby Power On/Off
Main Menu
with OSD controls
Front Control Panel
shown below in detail

ViewSonic VA2033-LED Specifications

General

3D	No
Aspect ratio	16:9
Display diagonal	20 \
Separate H/V sync	Yes
Display resolution	1600 x 900 pixels
Vertical scan range	50 - 75 Hz
Horizontal scan range	24 - 82 kHz
Viewing angle, vertical	160 °
Display number of colors	-
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
DVI-I ports quantity	0
Certification	UL, CUL, FCC-B (ICES), CB, CCC, CEL, WEEE, RoHS, ENERGY STAR 5.0, EPEAT-Silver, Windows 7
Product color	Black
Tilt angle range	5 - 20 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	22 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	130 mm
Package width	532 mm
Package height	450 mm
Package weight	4000 g
Cables included	AC, VGA
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	191.1 mm
Height (with stand)	376.1 mm
Weight (with stand)	2700 g
Depth (without stand)	61.5 mm
Width (without stand)	480 mm
Height (without stand)	304.8 mm
Weight (without stand)	2400 g
