ViewSonic VA2033-LED User Manual

ViewSonic VA2033-LED/VA2033a-LED 12
Main Menu Controls
Adjust the menu items shown below by using the up S and down T buttons.
Control Explanation
Auto Image Adjust automatically sizes, centers, and fine tunes the video signal
to eliminate waviness and distortion. Press the [2] button to obtain a sharper
image.
NOTE: Auto Image Adjust works with most common video cards. If this
function does not work on your LCD display, then lower the video refresh rate
to 60 Hz and set the resolution to its pre-set value.
Contrast adjusts the difference between the image background (black level)
and the foreground (white level).
Brightness adjusts background black level of the screen image.
Input Select toggles between inputs if you have more than one computer
connected to the LCD Display. (For VA2033-LED only)

ViewSonic VA2033-LED Specifications

General

3D	No
Aspect ratio	16:9
Display diagonal	20 \
Separate H/V sync	Yes
Display resolution	1600 x 900 pixels
Vertical scan range	50 - 75 Hz
Horizontal scan range	24 - 82 kHz
Viewing angle, vertical	160 °
Display number of colors	-
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
DVI-I ports quantity	0
Certification	UL, CUL, FCC-B (ICES), CB, CCC, CEL, WEEE, RoHS, ENERGY STAR 5.0, EPEAT-Silver, Windows 7
Product color	Black
Tilt angle range	5 - 20 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	22 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	130 mm
Package width	532 mm
Package height	450 mm
Package weight	4000 g
Cables included	AC, VGA
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	191.1 mm
Height (with stand)	376.1 mm
Weight (with stand)	2700 g
Depth (without stand)	61.5 mm
Width (without stand)	480 mm
Height (without stand)	304.8 mm
Weight (without stand)	2400 g
