10
Other Information
Specifications
Display Type
Display Size
Color Filter
Glass Surface
TFT (Thin Film Transistor), Active Matrix 1920 x 1080 Display,
0.2745 mm pixel pitch
Metric: 60.452 cm
Imperial: 24” (23.8” viewable)
RGB vertical stripe
Anti-Glare
Input Signal Video Sync RGB analog (0.7/1.0 Vp-p, 75 ohms)
HDMI (TMDS digital, 100ohms)
Separate Sync
f
h
:24-82 kHz, f
v
:50-75 Hz
Compatibility PC
Macintosh
1
Up to 1920 x 1080 Non-interlaced
Power Macintosh up to 1920 x 1080
Resolution
2
Recommended
Supported
1920 x 1080 @ 60 Hz
1680 x 1050 @ 60 Hz
1440 x 900 @ 60, 75 Hz
1280 x 1024 @ 60, 75 Hz
1024 x 768 @ 60, 70, 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
640 x 480 @ 60, 67, 72, 75 Hz
720 x 400 @ 70 Hz
Power Voltage 100-240 VAC, 50/60 Hz (auto switch)
Display area Full Scan 527.04 mm (H) x 296.46 mm (V)
20.7” (H) x 11.7” (V)
Operating
conditions
Temperature
Humidity
Altitude
+32 °F to +104 °F (0 °C to +40 °C)
20% to 90% (non-condensing)
To 10,000 feet
Storage
conditions
Temperature
Humidity
Altitude
-4 °F to +140 °F (-20 °C to +60 °C)
5% to 90% (non-condensing)
To 40,000 feet
Dimensions Physical 547.8 mm (W) x 403.7 mm (H) x 215 mm (D)
21.6” (W) x 15.9” (H) x 8.5” (D)
Wall Mount Distance
Screw
100 x 100 mm
[M4 x 8mm] x4
Weight Physical
8.8 lbs (4.0kg)
Power saving
modes
On
3
Off
31W (Typical) (Blue LED)
<0.3W
1
Macintosh computers older than G3 require a ViewSonic
®
Macintosh adapter. To order an adapter, contact
ViewSonic.
2
Do not set the graphics card in your computer to exceed these timing mode; doing so may result in permanent
damage to the display.
3
The test condition follows EEI standard
