ViewSonic Corporation Confidential - Do Not Copy
4
2. Specification
2.1 introductions
FEATURES VG2030m
Size
20.1
Luminance (Typ)
300 cd/
Contrast Ratio (Typ) 500:1
Colors 16.2 M colors
Response Time (Typ) 8 ms
Viewing Angle (H/V) 150 / 130 @CR>=10
170/ 150 @CR>= 5
TFTLCD PANEL
Recommend resolution 1400 X 1050 @60Hz
Analog (75ohms, 0.7/1.0 Vp-p) Yes
Input Signal
Digital Yes
Separate Sync Yes
Composite Sync No
Sync Compatibility
Sync on Green No
PC Yes
Power Mac Yes
Compatibility
TV Box (NextVision 6) Yes
Power Voltage AC 100-240V, 50/60Hz Yes
On Mode(Max / Typ) 55 W / 45 W
Power Consumption
Active Off Mode (Max) 1 W
Audio W 2.5W
Tilt
-5 ° ~ 20 °
Swivel ( -xx ° - xx °)
360
Pivot ( XX ° - XX °)
No
Ergonomics
Height Adjust ( XX-XX mm) 0-80mm
OSD Control [ ] [ 1 ] [ 2 ] [] [] [; X] Yes
Physical (W x H x D) 459 x 485 x 230(mm )
18.1 X 19.1 X 9.1 (in),
Dimension
Package (W x H x D) 520 x 560 x 290(mm)
20.4 x 22.0 x 11.4 (in)
Physical (lbs / Kg) 6.4 kgs ( 14.1 lbs)
Weight
Package (lbs / Kg) 8.33 kgs ( 18.3 lbs)
Temperature (/) 41-95 / 5-35
Operating Condition
Humidity (%) 20 % - 80 %
Temperature (/) -4-131 / -20-55
Storage Condition
Humidity (%) 20 % - 85 %
Regulation
CB / TCO03/ UL/cUL / FCC-B / ICES 003 / Argentina-TUV/S / NOM / EPA Energy Star /
TUV/Ergo / ISO13406-2 / TUV/GS / CE / GOST-R / SASO / BSMI / PSB / C-Tick / MIC /
CCC
VG2030m-1
