Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number# Q'ty
1
Accessories:
Power Code,UL,SVT#18/3C,75°C,LP-30B+LS-13,
L=1830+/-50mm,Black
A-00000458 32E1818015 1
2 Adapter - Lips With Audio,DAC-12M033 AF,00
A,12 V/0.7 A,5 V/3 A,4L,5 mA,2650 V
A-00005706 27-D004260 1
3
Board Assembly:
Power Switch Board ,A201P1-P01-H,A201P1-P01-
H-K1,1101-01,Rev.01
B-00005703 35-D007988 1
4 OSD BOARD ,A201P1-P01-H,A201P1-P01-H-
K2,1101-01,Rev.01
B-00005704 35-D007990 1
5 Audio Control Board ,A190A2-A02-H,A190A2-A02-
H-S1,1206-03,Rev.04
B-00005705 35-D005062 1
6
Cabinets:
Rear Assy,A201P1-H14,Black C-00005671 40-D007468 1
7 Cover Hinge Assy,A201P1-H14,Black C-00005672 40-D007467 1
8 Cover AD Assy C-00005673 41-D002955 1
9 Seat Assy,A201P1-H14,Black C-00005674 40-D007461 1
10 Bezel Assy,A201P1-H14,Silver/Black C-00005683 40-D007460 1
11 Stand Assy,A201P1-H14,Black C-00005684 40-D007465 1
12 Metal Frame Front,A201P1,SECC t=0.6mm C-00005685 41-D004344 1
13
Cables:
Accessory Cable,DVI,Black CB-00002083 32F0000004 1
14 Accessory Cable,D-Sub,BLACK CB-00004287 32F3018003 1
15 FFC,862P051787A/CFC2108,6 Pins CB-00005675 32-D007466 1
16 FFC,862P051786A/CFC2109,15 Pins CB-00005676 32-D007464 1
17 FFC,0.5x36x117xD(3.5/3.5/5/5),36 Pins CB-00005677 32-D008152 2
18 Accessory Cable,Audio,Black CB-00005678 32F2818011 1
19
Documentation:
Safety Label for ,A201P1-H04 DC-00005666 77-D007646 1
20 SN Label for ,A201P1-H04 DC-00005667 77-D007648 1
21 Carton Label for ,A201P1-H04,76.2 mmx76.2 mm DC-00005668 77-D007645 1
22 Carton Label for ,A201P1-H04,20 mmx20 mm DC-00005669 77-D008329 1
23 MENU for A201P1-H04 DC-00005670 76-D007999 1
24
Hardware:
Screw,M3*P0.5*6 HW-00000555 42A9930014 4
25 SCREW,M3,P=1.27 mm,L=8 mm HW-00000557 42A9930017 2
26 SCREW,M4,P=0.7 mm,L=8 mm HW-00004042 42-D000649 1
27 SCREW,M3,P=0.5 mm,L=4 mm HW-00005679 42A9930008 15
28 SCREW,M4,P=0 mm,L=11.8 mm M-00000559 42A9940007 4
29
Packing Material:
Bag,700 mmx500 mmx0.13 mm P-00002374 7841919941 1
30 Carton,A201P1-H04,490 mmx160 mmx510 mm P-00005680 78-D007998 1
31 Cushion,A201P1-H14,EPS,White,495 mmx150
mmx114 mm,EPS-FORM(Right),Green II
P-00005681 78-D007568 1
32 Cushion,A201P1-H14,EPS,White,495 mmx150
mmx114 mm,EPS-FORM(Left),Green II
P-00005682 78-D007563 1
Remark 1:
Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2: All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by
ViewSonic Corporation. This is to eliminate repeated cross checks of each item between this version and prior versions.
RECOMMENDED SPARE PARTS LIST (VG2021m-1)
Description
ViewSonic Model Number: VS11234
VG2021m-1 Confidential - Do Not Copy
