ViewSonic VG2439M-LED - Page 2

Specications
Sales: (888) 881-8781 or SalesInfo@ViewSonic.com • More product information: www.ViewSonic.com
*Energy savings may vary based on cost, actual usage and other factors. Specications and availability are subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details.Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2012 ViewSonic Corporation. All rights reserved. [16228-00B-06/12] VG2439m_LED
ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
LCD PANEL Type 24" (23.6" Viewable) Wide Color TFT Active Matrix LED
Display Area 20.5" horizontal x 11.5" vertical; 23.6" diagonal
Optimum Resolution 1920x1080
Brightness 300 cd/m
2
(typ)
Contrast Ratio 1000:1 static (typ)
Dynamic Contrast Ratio 20,000,000:1 dynamic
Viewing Angles 170º horizontal, 160º vertical
Response Time 5ms (typ.)
Backlight White-light LED
Backlight Life 30,000 hours (min)
Aspect Ratio 16:9
Panel Surface Anti-glare, hard-coating (3H)
INPUT Analog RGB analog (75 ohms, 0.7 / 1.0 Vp-p)
Digital DVI-D (TMDS, 100 ohms), Display Port
Sync H/V separated (TTL)
Frequency Fh = 24 ~ 82 kHz ; Fv = 50 ~ 75 Hz
AUDIO OUTPUT Speakers 2 watt (x2)
COMPATIBILITY PC VGA up to 1920x1080 @ 60Hz (preferred)
Mac
®
Power Mac (up to 1920x1080)
CONNECTOR Analog 15-pin mini D-sub (VGA)
Digital DVI-D (with HDCP), DisplayPort
Audio 3.5mm Audio In
3.5mm Headphones
Power Internal Power Board, 3-pin plug (CEE22)
POWER Voltage AC 100–240V (universal), +/-10% Wide Range
Consumption 24W (typ)
Optimize: 19W (typ)
Conserve: 15.5W (typ
CONTROLS Basic Power, 1, down, up, 2
OSD Auto Image Adjust, Contrast/Brightness, Input Select (D-SUB,
DVI), DisplayPort, Audio adjust (Volume Mute), Audio Input,
Color Adjust (sRGB, 9300K, 7500K, 6500K, 5000K, User
Color [R, G, B]), Information, Manual Image Adjust (H/V
Position, Horizontal Size, Fine Tune, Sharpness, Dynamic
Contrast, Response Time, Aspect Ratio, Eco-mode), Setup
Menu (Language, Resolution Notice, OSD Position, OSD
Timeout, OSD, Background, Auto Power Off), Memory Recall
ERGONOMICS Tilt -5-20º
Swivel 360º
Height Adjust 5.3" (0-135mm)
Pivot 0-90º
OPERATING Temperature 32–104ºF (0–40ºC)
CONDITIONS Humidity 10–90% (non-condensing)
DIMENSIONS Physical with stand 22.1 x 17.1 x 9.4 in. / 560.3 x 435.2 x 239.6 mm
(W x H x D) Physical without stand 22.1 x 13.1 x 2.3 in. / 560.3 x 332.7 x 58.2 mm
Packaging 25 x 20 x 7.5 in. / 634 x 508 x 190 mm
WEIGHT Net with stand 11.4 lb. / 5.2 kg
Net without stand 8.2 lb. / 3.7 kg
Gross 15.6 lb. / 7.1 kg
WALL MOUNT VESA
®
100 x 100 mm
REGULATIONS UL/cUL, FCC-B, ENERGY STAR
®
, EPEAT(Gold),
Mexico Energy, NOM, WEEE, RoHS, CE, CB
RECYCLE/DISPOSAL Please dispose of in accordance with local,
state or federal laws.
WARRANTY Three-year limited warranty on parts, labor and backlight
COUNTRY OF ORIGIN VG2439m-LED China
VG2439m-TAA Mexico
24" (23.6" Viewable)
Ergonomic LED Monitor
VG2439m LED Display, Power Cable, VGA Video Cable, DVI Cable, Audio Cable, USB Cable,
ViewSonic Wizard CD-ROM, Quick Start Guide
What's in the box?
VG2439m-LED / VG2439m-TAA
20,000,000:1 MEGA Dynamic Contrast Ratio
Dynamic contrast ratio detects the brightness of an image, and automatically
adjusts the backlight to maximize the monitor’s color range and contrast.
Dynamic contrast ratio technology enables the accurate reproduction of
images, producing vibrant and rich visual effects
.
VESA Wall MountKensington Security Lock
AC In
Dynamic Contrast RatioNormal
Height Swivel Tilt Pivot
Efciency & Comfort
The VG2439m is one of the great examples of an ergonomically designed
tool. Based on your height, chair and desk conditions, you can adjust it up and
down for 5.3 inches, swivel it 360°, or tilt it 20° degrees, whatever makes you
more comfortable.
USB x2 DVI-D
Headphone
USB
Upstream
Audio In VGADisplayPort
