ViewSonic Corporation Confidential - Do Not Copy VG2230wm-1
13
AUDIO INTERFACE (SPEAKER SPECIFICATION)
Speaker specification
Line input connection 3.5 mm stereo jack
Line input signal 1.0 Vrms
Line input impedance 10 kOhm
Maximum power output (Electric) 2 W (RL=4Ω)
Signal to Noise Ratio 72 dB
Frequency response 100 Hz – 20 Khz
Distortion < 10 % THD (@1kHz)
Vibration
There should be no audible vibration with volume at 100% and treble /
bass at default.
Screen image
There should be no affect on the screen image stability under any
conditions.
Connector PC99 requirement Audio in Lime Green pantone # 577C
Cable type / length 3.5mm stereo cable / 1.8m length
Audio DPMS Speakers should be off when the rest of the monitor is in power saving.
* No any sympathetic or abnormal noise allowed.
