ViewSonic Corporation Confidential - Do Not Copy VG2230wm-1
4
2. Specification
2.1 INSTRUCTION
1
LCD PANEL
(1
st
source)
Panel:
Size
Pixel Arrange
Glass Treatment
Contrast Ratio
Viewing Angle
Colors
Luminance
Response Time
Backlight
Backlight Life
Mercury
CR >= 10
On-Off
CMO A220Z1
22" Wide Color a-Si TFT Active Matrix 1680X1050 LCD
0.282 mm x 0.282 mm
Anti-Glare, Hard coating (3H)
700 :1
170/160 (degrees; typ)
16.2 million colors (6+2 bits)
280 cd/m2
5 ms
4 CCFL
60000 Hrs (Typ) / 50000 Hrs (Min)
3 mg per lamp
3 INPUT SIGNAL
Video
Sync
RGB Analog (75 ohms, 0.7 / 1.0 Vp-p), DVI (TMDS, 100 ohms)
Separate Sync / Composite Sync / SOG
Fh = 24 – 82 kHz ; Fv = 50 – 85 Hz
4 COMPATIBILITY
PC
Mac
PC Compatibles (from VGA up to 1680X1050 Non Interlaced)
Power Mac (up to 1680X1050 )
5
RESOLUTION
Recommended
Support
1680x1050@60Hz
640 x 350 @ 70Hz
640 x 400 @ 60, 70Hz
640 x 480 @ 50, 60, 67, 72, 75Hz
720 x 400 @ 70Hz
720 x 480 @ 60Hz
720 x 576 @ 50Hz
800 x 600 @ 56, 60, 72, 75Hz
832 x 624 @ 75Hz
1024 x 768 @ 50, 60, 70,75, 75Hz
1152 x 864 @ 75Hz
1152 x 870 @ 75Hz
1280 x 720 @ 50Hz
1280 x 768 @ 50, 60, 60, 75Hz
1280 x 960 @ 50, 60, 75Hz
1280 x 1024 @ 50, 60, 75Hz
6 AUDIO Speaker 2.5Wx2
7
CONNECTORS
Video
Power
Analog
Digital
DB-15
DVI-D
Internal Power Adapter, 3-pin plug (CEE22)
8 POWER Voltage AC 100-240V (Universal); 50/60 Hz
