ViewSonic VS11422 - Recommended Spare Parts List; Spare Parts Identification

ViewSonic Corporation Confidential - Do Not Copy VG2230wm-1
64
7. Recommended Spare Parts List
Serial No. Prefix: QC9 Rev: 1a
Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number#
1 Accessories: Power Cord,LP-53 & VCTF 0.75mm^2 3C A-00005071
32-D002330
2 On Screen Display Board, Rev.01 B-00005704
35-D007990
3 Power Supply Board (Lips W/ Audio Vo.7) B-00008026
27-D009542
4 Main Board Rev.04 B-00008027
35-D010627
5
Sub Board - PCBA Rev.02,ODM
B-00008119
35-D013204
6
Base Assembly
C-00008136
40-D013495
7
Back Cover - A220Z1-H07
C-00008137
40-D013273
8
Front Panel - (TY4818A)
C-00008138
40-D013268
9 DVI Cable, S/L, 1.8M, W/2F CB-00002083
32F0000004
10 Flat Cable (FFC,862P051786A/CFC2109,15 Pins) CB-00005676
32-D007464
11 Audio Cable (Accessory Black, 28AWG) CB-00005678
32F2818011
12 Accessory Cable,D-Sub, (30AWG) CB-00005851
32-D002132
13 Flat Cable (FFC 36 Pins) CB-00008014
32-D008479
14
Flat Cable - 6 Pins,Length 260mm,P 1.0mm
CB-00008042
32-D013272
15
Safety Label for ,A220Z1-H07,160 mmx30 mm
DC-00008131
77-D013322
16
Carton Label for ,A220Z1-H07,76.2 mmx76.2 mm
DC-00008132
77-D013175
17
CD-ROM
DC-00008133
76-D013171
18
SCREW,3,P=0.5 mm,L=4 mm,Pan Head,Phillips Cross Recess
HW-00000553
42A9930008
19 Screw, M4, P=0.7 mm, L=8 mm Round Head HW-00004042
42-D000649
20 SCREW,M4,P=0.7 mm,L=15 mm HW-00005884
42-D001756
21
SCREW,4,P=0 mm,L=11.8 mm,Hexagon Stand Off,Socket
HW-00006041
42A9940007
22
Screw - T3,P=1.058 mm,L=5 mm,Pan Head
HW-00008024
42-D003574
23
Screw - M3,P=0.5 mm,L=6 mm,Binding Head
HW-00008025
42-D005390
24 Miscellaneous: Tape Security, OPP,L900xW50x0.045mm M-00000560
7345511002
25 PE Bag,600 mmx650 mmx0.13 mm P-00008033
78-D009624
26
Foam - Top
P-00008133
78-D013271
27
Foam - Bottom White
P-00008134
78-D013275
28
Craft Box
P-00008135
78-D013323
29 Plastics: Panel Cover (Panel Protector Film) PL-00008008
73-D009538
Remark 1:
Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2:
RECOMMENDED SPARE PARTS LIST (VG2230wm-1)
Description
PC Board Assembly:
Cabinets:
Packing Material:
ViewSonic Model Number: VS11422
All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by ViewSonic
Corporation. This is to eliminate repeated cross checks of each item between this version and prior versions.
Cables:
Documentation:
Hardware:
