ViewSonic Model Number: VS11422
Rev: 1a
Serial No. Prefix: QC9
Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
1 N/A 73-C000047
ACF,COG,AC-8405Z-23 1.5mmX100M,100000 mmx1.5 mm,Hitachi Chemical,COG-
ACF,Green I
0.0028
2 N/A 36-D006411
Driver IC,COG,Scan,M170E5-L09,HX8653-
A000PD400,240/263/256Channel,Himax,(HX8633 shrank version),Green II
4
3 N/A L4M003XXXX 22"wide_TN, Photo Spacer ,Corning 0.7mm Glass , Resin/BM(Panel Base) 1
4 N/A L4M003XXBI 22”wide_TN, Photo Spacer ,Corning 0.7mm Glass , Resin/BM(Sheet Base) 0.0833
5 N/A 74-D007599
Polarizer,TFT,Degree 135,478.16 mmx300.2 mmx0.215
mm,XT300CMM220Z1H0B,M220Z1,LG Chem,LG HCR EWV
1
6 N/A 74-D007598
Polarizer,TFT,Degree 135,478.16 mmx300.2 mmx0.215
mm,XT300CMM220Z1H0B,M220Z1,LG Chem,LG HCR EWV
1
7 N/A 36-D007038
Driver IC,COF,Data,M220Z1-L01,HX8019-A07BCBC5,COF,6
bit,642Channel,Himax,Green II
8
8 N/A 73-D008216 ACF,COF,AC-4255U-16,200000 mmx1.2 mm,Hitachi Chemical,Green II 0.0025
9 N/A 73-D002676 ACF,PCB,AC-9825R-35,100000 mmx1.5 mm,Hitachi Chemical,PCB-ACF,Green I 0.005
10 N/A 35-D010045
PCBA for ,A220Z1-Z01-H,A220Z1-Z01-H-X,1101-03,Rev.04,USI/ITC,ODM,Green
II
1
11 N/A 7349951002 Silicone,TORAY/-9187L,330g 0.5
12 HW-00000553 42A9930008
SCREW,3,P=0.5 mm,L=4 mm,Pan Head,Phillips Cross Recess,Hama Naka Motogawa
Hama Naka Shoukin Shiho Shin Yee Shye Ching,Green I
13
13 HW-00006041 42A9940007
SCREW,4,P=0 mm,L=11.8 mm,Hexagon Stand Off,Socket,Shiho Shin Yee Shye
Ching Hama Naka Motogawa,Green I
4
14 HW-00004042 42-D000649
SCREW,M4,P=0.7 mm,L=8 mm,Round Head,Phillips Cross Recess,plate color
Zn,Screw_with_Washer,Shye Ching Hama Naka Motogawa Shin Yee,head D8,Green
I
1
15 N/A 41-D007402 Metal Frame Front,M220Z1-L01,SECC 0.6t,Fomgder/CLT_Metal,Green II 1
16 N/A 44-D008027 Backlight Unit,A220Z1,Forhouse/ROE,Green II 1
17 N/A 41-D008024
Cover AD Assy,A190A2,SECC,Jiin Ming,Left_Side 4
connector_VESA100*100,Green II
1
18 CB-00008014 32-D008479 FFC,CFC2128/862P060068D,36 Pins,Tennsure/Hung Fu, AL foil,Green I 2
19 HW-00008002 42-D009237
SCREW,M3,P=0.5 mm,L=2.5 mm,Pan Head,Phillips Cross Recess,Shye Ching,Green
II
3
20 B-00008026 27-D009542
Lips With Audio,DAC-19M009 AF,01 A,5 V/3 A,13.8 V0.7 A,I TYPE,7 mA,1710
V,Delta Dongguan_LIPS,Green II
1
21 B-00008027 35-D010627
PCBA for ,A220Z1-Z01-H,A170E2-E03-H-S6,1101-02,Rev.04,ITC
USI,ODM,RTD2120S-LF,Green II
1
22 HW-00008024 42-D003574
SCREW,T3,P=1.058 mm,L=5 mm,Pan Head,Phillips Cross Recess,Hama Naka
Motogawa Shye Ching,Green II
2
23 HW-00008025 42-D005390
SCREW,M3,P=0.5 mm,L=6 mm,Binding Head,Cross with Slotted Recess,Black
Zn,Shye Ching Shin Yee,Green II
4
24 CB-00005676 32-D007464 FFC,862P051786A/CFC2109,15 Pins,Hung Fu/TennRich,Green II 1
25 B-00005704 35-D007990
PCBA for ,A201P1-P01-H,A201P1-P01-H-K2,1101-01,Rev.01,ITC USI,ODM,Green
II
1
26 B-00008119 35-D013204
PCBA for ,A201P1-P01-H,A201P1-P01-H-K1,1101-02,Rev.02,ITC
TSMT,ODM,Green II
1
27 CB-00008042 32-D013272 FFC,6 Pins,Tennsure_FFC Hung Fu,Length 260mm,P 1.0mm,Green II 1
28 C-00008138 40-D013268 Bezel Assy,A220Z1-H07,BLACK(M1077)/SILVER(TY4818A),Push Power,Green II 1
29 C-00008137 40-D013273
Rear Assy,A220Z1-H07,BLACK (ABS PA757 J01 ),Push Power,Audio_in+DVI-
D,Green II
1
30 HW-00005884 42-D001756
SCREW,M4,P=0.7 mm,L=15 mm,Round Head,Phillips Cross
Recess,Zn(Black),Screw_with_Washer,Hama Naka Motogawa Shye Ching Shin
Yee,Green I
4
31 C-00008136 40-D013495 Stand Seat Assy,A220Z1-H07,Black,ViewSonic,VSC P/N:c-00006113,Green I 1
32 PL-00008008 73-D009538 Panel Protector Film,A220Z1-H03,XG-536 T=0.1mm,Just Enter,BLANK 1
33 N/A 77-D013177
SN Label for ,A220Z1-H07,50 mmx25 mm,Kunshan Hwakuan Chang
Huang,VSC_VG2230wm,Green II
1
34 DC-00008131 77-D013322
Safety Label for ,A220Z1-H07,160 mmx30 mm,Kunshan Hwakuan Chang
Huang,VSC_VG2230wm,Green II
1
35 HW-00002076 7841595111 Corner Protector,paper,50 mmx50 mmx1850 mm,Green II 0.2
36 N/A 7841595171 (AA),1140 mm,900 mm,11 mm,Non Green 0.05
37 DC-00000586 7741999141 Module Label,A190E2-H03,75 mm,40 mm,Non Green 0.05
38 M-00000560 7345511002 Tape,A170E1-H0P,900 mmx50 mmx0 mm,Symbio,OPP 0.007
39 N/A 78-D001493
Pallet,A170E1-H01,Wooden,1150 mmx920 mmx135 mm,Ming Li/Hua Sun
Paper/Shanghai Hang Wei 8,Green II
0.05
40 P-00008033 78-D009624 Bag,600 mmx650 mmx0.13 mm,PE Foam,650,Huang Jyii,Green II 1
41 DC-00008132 77-D013175
Carton Label for ,A220Z1-H07,76.2 mmx76.2 mm,Chang Huang Kunshan
Hwakuan,VSC_VG2230wm,Green II
1
42 DC-00008133 76-D013171
MENU for A220Z1-H07,Complex,1C,Yi Ching Car Tong Kunshan,VSC_VG2230wm
CD-ROM,Green II
1
43 P-00008133 78-D013271 Cushion,A220Z1-H07,EPS,White,560 mmx290 mmx175 mm,Li Ta,Top,Green II 1
44 N/A 79-D013274 Shipping Package Information for ,A220Z1-H07,VSC 1
45 P-00008134 78-D013275 Cushion,A220Z1-H07,EPS,White,560 mmx290 mmx150 mm,Li Ta,Bottom,Green II 1
BOM LIST ( VG2230wm-1 )
