ViewSonic VS11422 - Exploded Parts List Details; Block Diagram; System Block Diagram

ViewSonic Corporation Confidential - Do Not Copy VG2230wm-1
68
ViewSonic Model Number: VS11422
Rev: 1a
Item ViewSonic P/N Ref. P/N Description Q'ty
1
N/A
PM0ZFH0R00
ISM,A220Z1-H07 1
2
C-00008138
40-D013268
Bezel Assy,A220Z1-H07 1
3
CB-00005676 32-D007464 FCC,15 Pins,A220Z1-H07,ISM-Powerkey 1
4
CB-00008042
32-D013272
FCC,6 Pins,A220Z1-H07,OSD-Powerkey 1
5
N/A 32-D013204 PCBA for ,A201P1-P01-H-K1 1
6
B-00005704 35-D007990 PCBA for ,A201P1-P01-H-K2 1
7
HW-00008024 42-D003574 SCREW,T3,P=1.25 mm,L=5 mm 2
8
C-00008137
40-D013273 Rear Assy,A220Z1-H07 1
9
C-00008136
40-D013495 Stand Seat Assy,A220Z1-H07 1
10
HW-00008025 42-D005390
SCREW,M3,P=0.5 mm,L=6 mm 4
11
HW-00005884
42-D001756
SCREW,M4,P=0.7 mm,L=15 mm 4
EXPLODED PARTS LIST ( VG2230wm-1 )
