Initial Setup
This section provides instructions for setting up your monitor.
Wall Mounting
Refer to the table below for the standard dimensions for wall mount kits.
Maximum
Loading
Hole pattern
(W x H)
Interface Pad
(W x H x D)
Pad
Hole
Screw Specification &
Quantity
14 kg 100 x 100 mm 115 x 115 x 2.6 mm Ø 5 mm
M4 x 10mm
4 pieces
NOTE: Wall mount kits are sold separately.
IMPORTANT! Due to the design of the monitor, it is recommended the user does
not mount the monitor themselves. Please contact customer service for support.
Using the Security Slot
To help prevent the monitor from being stolen, use a security slot locking device to
secure the monitor to a fixed object.
Below is an example of setting up a security slot locking device on a table.
