ViewSonic VS18697

13
I/O Panel
Lower Right Side
HDMI OUTUSB USBTouch 1HDMI 1 (CEC) HDMI 2 (CEC/ARC) HDMI 3TOUCH 2
1
2 3 4 5 6
7
Boom Right
AUDIO OUTRS-232AUDIO IN
LAN
VGA
USBSPDIF
8 9 10 11 12 13 14
15 16
Boom Le
AUDIO OUTRS-232AUDIO IN
LAN
VGA
USBSPDIF
8 9 10 11 12 13 14
15 16
NOTE:
• TOUCH, HDMI, and VGA are grouped by color; i.e. TOUCH 1 should be used
with HDMI 1/2.
• Under Android, USB ports only support 2.0 le transfer speeds.
