ViewSonic VX2416 - Wall Mounting

11
Wall Mounng
NOTE: 
100 mm
100 mm
Refer to the table below for the standard dimensions for wall mount kits.
Maximum
Loading
Hole paern
(W x H)
Interface Pad
(W x H x D)
Pad Hole
Screw Specicaon
& Quanty
14 kg 100 x 100 mm 115 x 115 x 2.6 mm Ø 5 mm
M4 x 10 mm
4 pieces
NOTE: Wall mount kits are sold separately.
1. 
2. 
3. Remove the monitor stand.
4. 
device. Then secure it with four (4) screws (M4 x 10 mm).
5. 
monitor onto the wall.
