ViewSonic VX2418-PC-mhd - Wall Mounting

11
Wall Mounng
NOTE: Only use UL Cered wall mount kits.
HDMI 1 HDMI 2
DP
100 mm
Refer to the table below for the standard dimensions for wall mount kits.
Maximum Loading Hole paern (W x H) Screw Specicaon & Quanty
14 kg 100 x 100 mm
M4 x 10 mm
4 pieces
NOTE: Wall mount kits are sold separately. To obtain a wall mounng kit,
contact ViewSonic® or your local dealer.
1. Turn o the device and disconnect all cables.
2. Place the device on a at, stable surface with the screen facing down.
3. Remove the monitor stand.
1
1
2
2
4
3
4. Aach the mounng bracket to the VESA mounng holes at the rear of the
device. Then secure it with four (4) screws (M4 x 10 mm).
5. Follow the instrucons that come with the wall mounng kit to mount the
monitor onto the wall.
100 mm
