ViewSonic VX2835WM User Manual

ViewSonic VX2835wm 9
Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OSD controls which display
on the screen. The OSD controls are explained at the top of the next page and are defined in
“Main Menu Controls” on page 11.
Scrolls through menu
options and adjusts the
displayed control.
Audio Adjust (T) / OptiColor
(S)
Displays the control screen for
the highlighted control.
Also toggles between two
controls on some screens.
Also a shortcut to Auto Image
Adjust.
Standby Power On/Off
Power light
Blue = ON
Orange = Power Saving
Displays the Main
Menu or exits the
control screen and
saves adjustments.
Main Menu
with OSD controls
Front Control Panel
shown below in detail

ViewSonic VX2835WM Specifications

General

Display diagonal	28 \
Separate H/V sync	Yes
Display resolution	1920 x 1200 pixels
Vertical scan range	50 - 85 Hz
Horizontal scan range	24 - 82 kHz
Viewing angle, horizontal	160 °
Display brightness (typical)	500 cd/m²
RMS rated power	6 W
Certification	UL, cUL, FCC-B, CB, CE, NOM, NEMKO/GS ( TUV/GS), NEMKO ERGO, MPR II, GOST-R, SASO, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, RoHS, TCO'06
Product color	Black
Market positioning	-
Compatibility	PC / Mac
Power requirements	AC 100-240V, 50-60Hz
Mean time between failures (MTBF)	40000 h
Power consumption (typical)	64 W
Operating temperature (T-T)	20 - 55 °C
Operating relative humidity (H-H)	20 - 85 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	306 mm
Height (with stand)	578 mm
Weight (with stand)	12000 g
Depth (without stand)	87 mm
Width (without stand)	662 mm
Height (without stand)	489 mm
Weight (without stand)	8500 g
