ViewSonic VX2835WM User Manual

ViewSonic VX2835wm 11
Main Menu Controls
Adjust the menu items shown below by using the up S and down T buttons.
Control Explanation
Auto Image Adjust sizes and centers the screen image automatically.
Contrast adjusts the difference between the image background (black level)
and the foreground (white level).
Brightness adjusts background black level of the screen image.
Input Select toggles between inputs if you have more than one computer
connected to the LCD Display.
NOTE 1: Please press the power on/off key to restart monitor when changing
the HDMI input device.
NOTE 2: In HDMI input, please press “2” to switch display mode (AVQPC).
Audio Adjust
Volume increases the volume, decreases the volume, and mutes the audio.
Treble Adjusts the treble level.
Bass Adjusts the bass level.
Balance Adjusts left and right audio balance.
Mute temporarily silences audio output.

ViewSonic VX2835WM Specifications

General

Display diagonal	28 \
Separate H/V sync	Yes
Display resolution	1920 x 1200 pixels
Vertical scan range	50 - 85 Hz
Horizontal scan range	24 - 82 kHz
Viewing angle, horizontal	160 °
Display brightness (typical)	500 cd/m²
RMS rated power	6 W
Certification	UL, cUL, FCC-B, CB, CE, NOM, NEMKO/GS ( TUV/GS), NEMKO ERGO, MPR II, GOST-R, SASO, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, RoHS, TCO'06
Product color	Black
Market positioning	-
Compatibility	PC / Mac
Power requirements	AC 100-240V, 50-60Hz
Mean time between failures (MTBF)	40000 h
Power consumption (typical)	64 W
Operating temperature (T-T)	20 - 55 °C
Operating relative humidity (H-H)	20 - 85 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	306 mm
Height (with stand)	578 mm
Weight (with stand)	12000 g
Depth (without stand)	87 mm
Width (without stand)	662 mm
Height (without stand)	489 mm
Weight (without stand)	8500 g
