ViewSonic Model Number: VS10162-3W
Rev: 1a
Item ViewSonic P/N Ref. P/N Description Q'ty
1 C-00000987 EAL9V001018 BEZEL L9V(EAL9V001,REV3A) 1
2 C-FP-0301-1047 EAL9V002014 MIDDLE BEZEL L9V(EAL9V002,REV3A) 1
3 PL-BT-0706-0165 EBL7V027012 CONTROL BUTTON L7VD(EBL7V027,REV3A) 1
4 M-MS-0808-9243 FEL7V003019 LOGO FRONT-VSC-38CM L7VC(FEL7V003,REV3A) 1
5 M-MS-0808-9401 EBL7V028019 LENS L7VD(EBL7V028,REV3A) 1
6 M-MS-0808-9402 FEL7V007014 BIRD LOGO L7VD(FEL7V007,REV3A) 1
7 B-CB-0206-0188 23L7VBB0034 L7VD BUTTON/B ASSY 1
8 HW-00001802 FBL9V010018 LCD PANEL LOCK METAL L9V 2
9 M-SCW-0824-0726 MF30080BBJ5 SCREW F3.0*8L,B,NI 2
10 E-00001775 AAM190EN129 LCD(TFT) 19" M190EN04 REV:V5 1
11 HW-00001807 FBL9V009010 LCD BKT L9V(FBL9V004,REV3A) 2
12 M-SCW-0824-6802 MM30040IBJ9 SCREW M3.0*4.0-I(NI) GP 4
13 M-BK-0805-0079 FAL7V014017 PCB BKT L7VD(FAL7V014,REV3A) 1
14 CB-00002522 DD0L9V0B000 CABLE MB-OVER DRIVER(30P,50MM) L9V-5 GP 1
15 B-PS-0204-0076 AS02B012D24 ADD/INV,FSP035-1PI01,90~264V REV1A 1
16 B-00002519 29L9IMB00E5 L9I M/B ASSY (FOR L9VDA-5 REALTEK2523)AU 1
17 M-MS-0808-9398 DDL7VDTH009 CABLE ASSY L7VD BUTTON-MB (8P-10P) 1
18 M-SCW-0824-6799 MM35080BBW2 SCREW M3.5*8-B (NI,WASHER) 1
19 M-SCW-0824-6800 MM30060IBJ8 SCREW M3.0*6.0-I(NI) 7
20 M-MS-0808-9405 FAL7V015013 PCB SHIELDING L7VD(FAL7V015,REV3A) 1
21 HW-00000989 MM30040IBJ8 SCREW M3.0*4.0-I(NI) 10
22 M-MS-0808-9811 GAL5M002011 RUBBER FOOT L5M(GAL5M002,REV3B) 4
23 M-SCW-0824-0813 MF30060BBJ6 SCREW F3.0*6-B(NI) 1
24 M-CV-0830-2589 EAL9V005013 STAND BKT COVER L9V(EAL9V005,REV3A) 1
25 M-MS-0808-9812 EBL9V001019 STAND COVER F L9V(EBL9V001,REV3A) 1
26 M-BK-0805-0110 FBL9V005014 STAND BKT L9V(FBL9V005,REV3A) 4
27 C-BS-0303-0553 EAL9V004017 STAND BASE L9V(EAL9V004,REV3A) 1
28 M-MS-0808-9813 FBL9V006011 STAND PLATE L9V(FBL9V006,REV3A) 1
29 M-SCW-0824-6859 MM40060IL69 SCREW M4*6-I (BNI)(NYLOK)) 4
30 M-SCW-0824-6894 MF30060BJ28 SCREW F3.0*6-B(BNI) 4
31 M-MS-0808-9404 EBL7V029015 WIRE CLAMP L7VD(EBL7V029,REV3A) 2
32 C-00001778 EBL9V002015 STAND COVER R L9V(EBL9V002,REV3A) 1
33 M-SCW-0824-6895 MF40080IBJ1 SCREW F4.0*8-I(NI) 8
34 M-BK-0805-0111 FBL9V002015 HNGE-BKT L9V(FBL9V002,REV3A) 1
35 M-CV-0830-2590 FBL9V001019 HINGE-L L9V(FBL9V001,REV3A) 1
36 M-CV-0830-2591 FBL9V003011 HINGE-R L9V(FBL9V003,REV3A) 1
37 M-MS-0808-9411 FBL70008014 LOCK METAL L70B(FBL70008,REV3A) 1
38 M-CV-0830-2592 EAL9V003011 LCD COVER L9V(EAL9V003,REV3A) 1
39 M-SCW-0824-6859 MM40060IL69 SCREW M4.0x6 (BNI)NYLOCK 6
40 M-CV-0830-2593 EBL9V003011 I/O COVER L9V(EBL9V003,REV3A) 1
41 M-MS-0808-9253 FEL7V005011 LOGO PLATE 1
42 M-SCW-0824-0870 MS40070B808 SCREW M4.0x7 (BMC)NYLOCK 4
43 M-MS-0808-9815 GAL9V002014 RUBBER PLUG VESA L9V 4
44 PL-00001804 GAL70002015 RUBBER HOLDER 2
45 PL-00001805 GAL70005014 RUBBER BKT 2
46 PL-00001806 GAL5T001016 RUBBER HOLDER 4
47 CB-00002525 DD0L9VLC015 CABLE MB-LCD(30P, 140MM) 1
48 N/A MBL9V001019 IO NUT L9VDA-5 2
49 B-00002520 22L9V0B0005 L9V OVER DRIVER/B ASS'Y 1
EXPLODED PARTS LIST (VX924-1)
59
ViewSonic Corporation Confidential
-
Do Not Copy VX924
