ViewSonic VX924 Service Manual

ViewSonic Model Number: VS10162-3W
Rev: 1a
Item ECR/ECN ViewSonic P/N Ref. P/N Location Q'ty
1 main board B-00002519 29L9IMB00E5 main board 1
2 Over driver board B-00002520 22L9V0B0005 Over driver board
3 Power board B-PS-0204-0076 AS02B012D24 power board 1
4
Back cover assy
C-BC-0302-0626
33L9VBCVS05
back cover 1
5 Front bezel assy C-FP-0301-1033
32L9VFBVS07
front bezel ass'y 1
6 Stand cover rear C-00001778
EBL9V002015
stand cover 1
7 Cable for MB-B/B (8P/10P. Rev.1A) M-MS-0808-9398 DDL7VDTH009 M/B-B/B cable 1
8 Cable for MB-LCD (30P. Rev.1A) CB-00002525
DD0L9VLC015
MB-LCD cable 1
9 Cable for MB-over driver CB-00002522 DD0L9V0B000 MB-over driver cable
10 VGA cable M-MS-0808-9399 DDL7VDPC005 VGA cable 1
11
Documentation:
User manual + CD wizard DC-00002523 HGL9V0011019 user's manual 1
12
Electronic
Components:
19" AUO TFT LCD panel E-00001775 AAM190EN129 LCD panel 1
13 Screw M4*6-I (BNI)(NYLOK) M-SCW-0824-6859
MM40060IL69
Screw 4
14 Screw M3.0*4.0-I(NI) M-SCW-0824-6802
MM30040IBJ9
Screw 14
15 LCD film L9V M-MS-0808-9682 JXL9V001010 LCD panel film 1
16 4ms sticker M-00002524
HCL9V007018
4ms sticker on carton 1
17 Carton P-00002521 HFL9V007011 carton 1
18 End cap (L) P-FM-0602-0896
HBL9V001019
cushion 1
19 End cap (R) P-FM-0602-0897
HBL9V002015
cushion 1
20 EPE bags M-MS-0808-9817 HAL9V002014 EPE bags 1
Cables:
RECOMMENDED SPARE PARTS LIST (VX924-1)
Description
PC Board Assembly:
Cabinets:
Miscellaneous:
Hardware:
Packing Material:
55
ViewSonic Corporation Confidential
-
Do Not Copy VX924
7. Recommended Spare Parts List
