ViewSonic VX924 Service Manual

ViewSonic Model Number: VS10162-3W
Rev: 1a
Item ViewSonic P/N Ref. P/N Description Location Q'ty
1 #N/A 1L9VDZAVS92 L9V LCD MONITOR(L9VDA-5,AU VX924)US
2 B-00002519 29L9IMB00E5 L9I M/B ASSY(FOR L9VDA-5 REALTEK,2523)AU 1
3 #N/A 39L9IDP0056 L9I M/B DIP ASSY(L9VDA-5 REALTEK)2523 1
4 #N/A 41L9ISS0053 L9I M/B S/S ASSY(L9VDA-5 REALTEK)2523 1
5 #N/A CC62204MD23 CAP ELEC 22U 25V(+-20%,105C,5*11,2000HR)
C34,C46,C50,C53,C59,C84,EC1,EC2
,EC3,EC5,EC6
11
6 #N/A CC622L4MD06 CAP ELEC DIP 22U 25V(+-20%,105C,5*11)LXN
C34,C46,C50,C53,C59,C84,EC1,EC2
,EC3,EC5,EC6
11
7 #N/A CC71004MD68 CAP ELEC 100U 25V +-20%,105C,6*11,LESR C70 1
8 #N/A CC710L4MD08 CAP ELEC 100U 25V(+-20%,105C,6*11)LXN C70 1
9 #N/A CC73303MD51 CAP ELEC 330U 16V(+-20%,105C,8*11,2000HR C6,EC4 2
10 E-L-0407-1563 DC04725K002 CHOKE COIL 47UH(2.5A,+-10%,T07473) L2 1
11 #N/A BG624576031 CRYSTAL DIP 24.576MHZ(30PPM,20PF,49/US) Y1 1
12 #N/A BG611059319 CRYSTAL DIP 11.0592MHZ(+-30PPM,49/US) Y2 1
13 #N/A DFHD06MR247 CONN DIP HEADER 6P 2R MR(P2.5,H6.0) CN1 1
14 #N/A DFDS15FR050 CONN D-SUB 15P 3R FR,P1.15,H12.55,NO SRW CN2 1
15 #N/A DFDI30FR049 CONN DVI-I DIP30P 3R FR(P1.905,H10.04) CN4 1
16 M-MS-0808-9809 DFHD30MR259 CONN DIP HEADER 30P 2R MR(P2.0,H4.0) CN5 1
17 M-MS-0808-9810 DFHD10MR316 CONN DIP HEADER 10P 1R MR(P2.0,H4.1) CN6 1
18 #N/A AZL9VD0A206 L9VDA-5 SW BIOS IMAGE REALTEK(AU)2523 1
19 B-00002520 22L9V0B0005 L9V OVER DRIVER/B ASSY 1
20 #N/A DA0L9V0B2B8 PCB(OD/B) L9V ODB(2L,85*90MM REVB) 1
21 #N/A AJ036010F00 IC(208P)LCD OVERDRIVE VTIO3601(LQFP) U4 1
22 #N/A AKD24G-K501 IC SDRAM(50P) K4S161622H-TC60 TSOP U2,U5,U6,U7 4
23 #N/A AKE24FU0K13 IC FLASH SST25VF512A-33-4C-SAE SO8 GP U3 1
24 #N/A AL001084013 IC(3P) L1084D(TO-252) U1 1
25 #N/A CH41004Z931 CAP CHIP 0.1U,25V(+80-20%,Y5V,0603) GP
C2,C4,C6,C7,C8,C9,C10,C11,C12,C1
3,C14,C15,C16,C17,C34,C35,C36,C3
7,C38,C39,C40,C41,C42,C43,C44,C4
5,C60,C61,C62,C63,C64,C65,C66,C6
7,C68,C69,C70,C71,C72,C73,C76,C7
7,C78,C79,C80,C81,C82,C83,C84,C8
5,C86,C87,C88,C89
54
26 #N/A CH61001ZA31 CAP CHIP 10U 6.3V(+80%-20%,Y5V,0805)
C1,C3,C5,C18,C19,C21,C22,C23,C24
,C32,C33,C58,C59,C74,C75
15
27 #N/A CJ033084N16 RES ARRAY CHIP 33,1/16W(5%,8P4R)R-PIN
PR1,PR2,PR3,PR4,PR5,PR6,PR7,PR
8,PR9,PR10,PR11,PR12,PR13,PR14,
PR15,PR16
16
28 #N/A CS03303J909 RES CHIP 33 1/10W +-5%(0603) R21 1
29 #N/A CS11003F902 RESISTOR CHIP 100 1/10W+-1%(0603)
R3,R4,R5,R6,R7,R9,R10,R11,R12,R1
3
10
30 #N/A CS12003F905 RESISTOR CHIP 200 1/10W+-1%(0603) R1 1
31 #N/A CS13303F909 RESISTOR CHIP 330 1/10W +-1%(0603) R2 1
32 #N/A CS31003J908 RES CHIP 10K 1/10W +-5%(0603) R8 1
33 #N/A CS21003J906 RES CHIP 1K 1/10W +-5%(0603) R14 1
34 #N/A DFHD30MS026 CONN SMD HEADER 30P 2R MS(P2.0,H4.0) JP1,JP2 2
35 #N/A CX201209805 EMI FILTER CHIP FBM-11-201209-121A40 GP L1,L2,L3,L4,L5 5
36 B-CB-0206-0188 23L7VBB0034 L7VD BUTTON/B ASSY 1
37 #N/A DFHD08MR301 CONN DIP HEADER 8P 1R MR(P2.0,H4.1) CN1 1
38 #N/A BEYG0013DA3 LED(DIP) YELLOW/GREEN(L-3WYGW) LED1 1
39 #N/A DAL7VDTB1A3 PCB(BUTTON) L7VD TL(1L,180*15,REVA) 1
40 #N/A DHP0002B205 SWITCH PUCH BUTTON(PT-002-B2,50MA,12V) SW1,SW2,SW3,SW4,SW5 5
41 B-PS-0204-0076 AS02B012D24 ADD/INV,FSP035-1PI01,90~264V REV1A 1
42 #N/A 23L9VLAVS63 L9VDA-5 LCD MOUDLE ASSY(AU,VX924) 1
43 C-FP-0301-1033 32L9VFBVS07 L9V FRONT BEZEL ASSY 1
44 C-00000987 EAL9V001018 BEZEL L9V(EAL9V001,REV3A) 1
45 C-FP-0301-1047 EAL9V002014 MIDDLE BEZEL L9V(EAL9V002,REV3A) 1
46 M-MS-0808-9401 EBL7V028019 LENS L7VD(EBL7V028,REV3A) 1
47 PL-BT-0706-0165 EBL7V027012 CONTROL BUTTON L7VD(EBL7V027,REV3A) 1
48 M-MS-0808-9243 FEL7V003019 LOGO FRONT-VSC-38MM L7VC(FEL7V003,REV3A) 1
49 M-MS-0808-9402 FEL7V007014 BIRD LOGO L7VD(FEL7V007,REV3A) 1
50 C-BC-0302-0626 33L9VBCVS05 L9V BACK COVER ASSY 1
51 M-CV-0830-2592 EAL9V003011 LCD COVER L9V(EAL9V003,REV3A) 1
52 M-MS-0808-9253 FEL7V005011 LOGO PLATE ELLIPSE L7VC(FEL7V005,REV3A) 1
53 M-MS-0808-9411 FBL70008014 LOCK METAL L70B(FBL70008,REV3A) GP 1
54 M-CV-0830-2590 FBL9V001019 HINGE -L L9V(FBL9V001,REV3A) 1
55 M-BK-0805-0111 FBL9V002015 HNGE-BKT L9V(FBL9V002,REV3A) 1
56 M-CV-0830-2591 FBL9V003011 HINGE-R L9V(FBL9V003,REV3A) 1
57 M-SCW-0824-6895 MF40080IBJ1 SCREW F4.0*8-I(NI) 8
58 M-SCW-0824-6859 MM40060IL69 SCREW M4*6-I (BNI)(NYLOK)) 6
59 E-00001775 AAM190EN129 LCD(TFT) 19" M190EN04 REV:V5 1
60 M-BK-0805-0079 FAL7V014017 PCB BKT L7VD(FAL7V014,REV3A) 1
61 M-MS-0808-9405 FAL7V015013 PCB SHIELDING L7VD(FAL7V015,REV3A) 1
62 HW-00001807 FBL9V009010 LCD BKT L-R L9VD-1(FBL9V009,REV3A) 2
63 HW-00001802 FBL9V010018 LCD PANEL LOCK METAL L9VD1(FBL9V010,R3A) 2
BOM LIST (VX924-1)
56
ViewSonic Corporation Confidential
-
Do Not Copy VX924
