ViewSonic VX924 Service Manual

Item ViewSonic P/N Ref. P/N Description Location Q'ty
64 M-SCW-0824-0726 MF30080BBJ5 SCREW F3.0*8L,B,NI 2
65 M-SCW-0824-6802 MM30040IBJ9 SCREW M3.0*4.0-I(NI) GP 14
66 M-SCW-0824-6800 MM30060IBJ8 SCREW M3.0*6.0-I(NI) GP 11
67 M-SCW-0824-6799 MM35080BBW2 SCREW M3.5*8-B (NI,WASHER) 1
68 M-MS-0808-8986 MBLI1004018 IO NUT LI1(MBLI1004,REV3A) 4
69 M-MS-0808-9247 EBL70023013 WIRE MOUNTS L70L-E(EBL70023,REV3A) GP 1
70 #N/A EBL7V030013 PCB SPACER L7VD(EBL7V030,REV3A) 1
71 PL-00001804 GAL70002015 RUBBER-HOLDER L70L(GAL70002,REV3B) 2
72 PL-00001806 GAL5T001016 RUBBER-HOLDER L5TL-E(GAL5T001,REV3B) 4
73 PL-00001805 GAL70005014 RUBBER-BKT(T) L70L-T(GAL70005,REV3A) 2
74 #N/A MBL9V001019 IO NUT L9VDA-5(MBL9V001,REV3A)M3*15*6 2
75 #N/A GAL7E002013 LCD RUBBER L7E(GAL7E002,REV3B) 1
76 C-BS-0303-0553 24L9VSAVS02 L9V STAND ASSY 1
77 #N/A 34L9VSBVS08 L9V STAND BKT ASSY 1
78 C-BS-0303-0553 EAL9V004017 STAND BASE L9V(EAL9V004,REV3A) 1
79 M-MS-0808-9811 GAL5M002011 RUBBER FOOT L5M(GAL5M002,REV3B) 4
80 M-CV-0830-2589 EAL9V005013 STAND BKT COVER L9V(EAL9V005,REV3A) 1
81 M-SCW-0824-0813 MF30060BBJ6 SCREW F3.0*6-B(NI) 9
82 M-MS-0808-9812 EBL9V001019 STAND COVER F L9V(EBL9V001,REV3A) 1
83 M-MS-0808-9404 EBL7V029015 WIRE CLAMP L7VD(EBL7V029,REV3A) 2
84 M-SCW-0824-6894 MF30060BJ28 SCREW F3.0*6-B(BNI) 4
85 #N/A 25L9VCSVS50 L9VDA-5 CHASSIS ASSY(VX924) 1
86 CB-00002525 DD0L9VLC015 CABLE MB-LCD(30P,140MM)L9V-5 GP 1
87 M-MS-0808-9398 DDL7VDTH009 CABLE ASSY L7VD BUTTON-MB(8P/10P,REV1A) 1
88 C-00001778 EBL9V002015 STAND COVER R L9V(EBL9V002,REV3A) 1
89 M-CV-0830-2593 EBL9V003011 I/O COVER L9V(EBL9V003,REV3A) 1
90 M-SCW-0824-6859 MM40060IL69 SCREW M4*6-I (BNI)(NYLOK)) 4
91 M-SCW-0824-0870 MS40070B808 SCREW M4*7B (BMC)NYLOK 4
92 M-MS-0808-9815 GAL9V002014 RUBBER PLUG VESA L9V(GAL9V002,REV3A) 4
93 CB-00002522 DD0L9V0B000 CABLE MB-OVER DRIVER(30P,50MM)L9V-5 GP 1
94 #N/A 26L9VPKVSP1 L9VDA-5 PACKING ASSY(AU,VX924)US 1
95 M-MS-0808-9399 DDL7VDPC005 CABLE ASSY L7VD MB-VGA (15/15P,REV1A) 1
96 A-PC-0106-0224 DM333181G97 POWER CORD 3P 1.8M(USA)V04VS35001218000 1
97 M-MS-0808-9817 HAL9V002014 EPE BAG L9VD(HAL9V002,REV3A) 1
98 P-FM-0602-0896 HBL9V001019 END CAP-L L9V(HBL9V001,REV3A) 1
99 P-FM-0602-0897 HBL9V002015 END CAP-R L9V(HBL9V002,REV3A) 1
100 M-LB-0813-0747 HCL7V004013 CORE LABEL(HCL7V004,REV3A) 1
101 #N/A HCL9V006011 ID LABEL VX924 L9VDA-5(HCL9V006,REV3A) 1
102 M-LB-0813-0745 HCL7V002011 SERIAL LEBAL L7V(HCL7V002,REV3A) 1
103 M-LB-0813-1042 HCL7V019011 CARTON LABEL L7VC(HCL7V019,REV3B) 1
104 P-00002521 HFL9V007011 CARTON VX924 L9VDA-5(HFL9V007,REV3A) 1
105 #N/A HGL9V011019 CD+QSG VX924 L9VDA-5 USA(HGL9V011,REV3A) 1
106 #N/A JXLM5003011 HANDLE LM5S(JXLM5003,REV 3B) GP 1
107 M-MS-0808-9682 JXL9V001010 LCD FILM L9V(JXL9V001,REV3A) 1
108 M-LB-0813-1043 HCL70021011 HI-POT LABEL L70L(HCL70021,REV3A) 1
109 #N/A HFL9V002019 SPACE PLATE L9V(HFL9V002,REV3A) 0.05
110 M-00002524 HCL9V007018 4MS STICKER VX924 L9VD(HCL9V007,REV3A) 1
