6
2-2. The Exterior of the Monitor
A. Front B. Left and Right
1
C. Rear
11 32
1. I/O port (input/output)
This area should include all I/O
connection options, as well as the
power input connector (Expanded in
2-4)
2. Kensington security slot
(Expanded in 2-3 section G)
3. VESA wall mounting
This area on the back of the monitor*.
For the VESA wall mounting
installation steps, please see 2-3
section F for additional instructions.
