ViewZ 22-INCH TFT-LCD - Camera Sensor Specifications

2. Camera Specification
ITEM
Built-in CAMERA
Image Sensor
1/3” C-MOS
Effective Pixels
720(H) X 540(V)
Sync System
INT / LL Selectable
Electronic Shutter
Up to 1/22,000 sec.
Main Video Output
1.0 Vp-p Composite, 75 ohm
Service Monitor Output
1.0 Vp-p Composite, 75 ohm
Horizontal Resolution
540 TV Lines (High Resolution mode) / F1.2
Min. Illumination
0.1 Lux (Slow Shutter Mode)
Dynamic Range
120dB(max), 102dB(typical)
AGC Control
0~46dB
Iris Control
DC / Video
DNR
OFF / AUTO
Lens Mount
C/CS Mount (Screw Lock)
Camera Control & Setup
OSD Menu
Power Consumption
Max. 200mA
Power Requirement
DC 12V / AC24V Dual Voltage
Operating Temperature
0℃ ~ 45℃
Operating Humidity
Within 90% RH
Dimensions
63.7(W) X 64.0(H) X 87.4(D) mm
Weight
350g
▶▶ NOTE: Technical specifications are subject to change without notice.
28 ………………………………………………………………………. INSTRUCTION MANUAL
