ViewZ 22-INCH TFT-LCD - CONNECTING EXTERNAL EQUIPMENT; Top Panel Input;Output Ports

A. TOP PANEL CONTROL
A-1. AC IN Type
1. DC 12V IN
2. HDMI IN
3. DVI IN
5. PC STEREO IN
7. S-VIDEO (Y/C) IN
10. CAMERA OUT
11. AV2 (VIDEO2) IN
13. AC IN
15. SD CARD READER (Optional)
A-2. AC 24V IN Type
4. VGA (D-SUB) IN
6. AUDIO OUT (Speaker)
8 & 9. AUDIO IN(R+L) for AV1, AV2
and S-VIDEO
12. AV2 (VIDEO2) OUT
14. USB 2.0 (Optional)
1. DC 12V IN
2. HDMI IN
3. DVI IN
5. PC STEREO IN
7. S-VIDEO (Y/C) IN
10. CAMERA OUT
11. AV2 (VIDEO2) IN
13. AC 24V IN
15. SD CARD READER (Optional)
4. VGA (D-SUB) IN
6. AUDIO OUT (Speaker)
8 & 9. AUDIO IN(R+L) for AV1, AV2
and S-VIDEO
12. AV2 (VIDEO2) OUT
14. USB 2.0 (Optional)
6 …………………………………………….……………………………INSTRUCTION MANUAL
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
