ViewZ VZ-215D2IP - Page 16

21.5”
LCD Type
21.5˝ Diagonal AM-TFT(Active-Matrix)
Pixel pitch(mm): 0.24825(H) x 0.24825(V)
Brightness: 250cd/m² (Typical)
Contrast ratio: 1000:1 (Typical)
Viewing angle: 170°/160° (H/V)
Response time: 5ms (Typ., on/off)
Resolution (H x V)
1920X1080 @60Hz
Frequency
Horizontal: 31~80kHz,
Vertical: 56~60Hz
Input Signal
UPGRADE 1-2
UPGRADE SELECT S/W
RJ45
IP RESET
HDMI IN
Active Display
Area (H x V)
476.64mm x 268.11mm
Packing Dimensions
(W x H x D)
580mm x 440mm x 145mm
(22.83” x 17.32” x 5.71”)
Weight
Net: 4.18kg (9.21 lbs)
Gross: 5.55kg (12.23 Ibs)
Electrical Ratings
12V 3.0A (100~240V, 50/60Hz)
▶▶ NOTE: Technical specifications are subject to change without notice.
- 14 -
