Vigia NM 343 - Inflation Module Details; Module Function and Connections

4
Ination module
Made of electrovalves and electronic sensors.
It controls the tire pressure permanently and it sends the informationto
the control panel.
VOLTAGE
INDICATOR
DEPOSIT AIR
INLET
ELECTRICAL COMMU-
NICATION CONNECTOR
(CAN BUS) TO THE
CONTROL PANEL AND
TO THE ELECTRICAL
POWER SOCKET
AIR PRESSURE
OUTLET 1, 2 AND 3
TO THE TIRES
