Viking Range 7 Series User Manual

10
Range Features (VDR/CVDR Gas Range)
Interior Oven
Light Switch
Left Rear Burner
Control Knob
(8,000 BTU)
Left Front Burner
Control Knob
(23,000 BTU)
Left Oven
Selector
Knob
Right Rear Burner
Control Knob
(15,000 BTU)
Right Front Burner
Control Knob
(23,000 BTU)
Right Oven
Selector
Knob
3
1
2
6
5
8
7
Center Left Rear Burner
Control Knob
(15,000 BTU)
Center Left
Front Burner
Control Knob
(23,000 BTU)
Center Right
Rear Burner
Control Knob
(15,000 BTU)
Center Right
Front Burner
Control Knob
(23,000 BTU)
Left Oven
Temperature
Control Knob
Right Oven
Temperature
Control Knob
4
9
1. Front 23,000 BTU burners
2. Rear 15,000 BTU burners
3. Rear 8.000 BTU burner
4. Island trim
5. Identification plate (under control panel)
6. 30” Oven-Three TruGlide racks/Six rack positions
7. 18” Oven-Two standard tilt-proof racks/Six rack positions
8. Night Light Switch (under bullnose)
9. Lighted Bezel Switch (under bullnose)
Night Light Switch:
When switched to on position, all of the rings behind the knobs will display the user’s preselected light color.
Lighted Bezel Switch:
To change the color of the bezel light, hold the switch until the bezel color changes and then release the switch.
