Flush Mount Side Trim
After the unit has been placed in the cutout, leveled and all connections completed, the unit will need to be
fastened to the cabinetry. Open the door and remove the drawers. Using the at wood screws, fasten the
unit to the cabinetry on both sides. NOTE: Only use the screws provided and use caution when installing
the fastening screws to prevent scratching the frame. Use a 3" Phillips driver to prevent damage. Snap the
ush mount side trim to the side opposite the door swing. Replace the drawers and close the door.
Attach unit to cabinetry on both
sides
Side trim is taped to the side unit.
Remove and snap to side opposite
door swing.
