Viking CFGNI515 - Page 7

7
3. Open door and locate screws at upper back wall of bin. Remove the two screws
4. Remove the back panel of the bin by lowering it down past the scoop holder, feel free to rotate the scoop holder
loop down to make more room.
Screws
ON/OFF
ICE
MAKING
CHECK
WATER
TIME TO
CLEAN
CLEAN
RESET
Care and Cleaning (con’t)
Reservoir Cover
Release Tab
Float Valve
On/O Lever
5. Push tab on front edge of reservoir cover and remove the cover. Note: Adjacent wires are low voltage and are not
hazardous.
Push Tab
Lift reservoir cover to remove
