Viking DMOR205SS - Page 52

50
VMOR205SS
DMOR205SS
REF. NO. PART NO. DESCRIPTION Q'TY
OVEN PARTS
4- 1 FFTA-B004MRK0 Exhaust damper assembly 1
4- 2 FROLPB027MRK0 Turntable support assembly 1
4- 3 NTNT-A114WREZ Turntable tray 1
4- 4 LANGKB010MRP0 Capacitor holder 1
4- 5 FCOVPB002MRY0 Stirrer cover assembly 1
4- 6 FFAN-B008MRK0 Stirrer fan assembly 1
4- 7 ------------- Oven cavity (not replaceable) 1
4- 8 DHET-B001MRK0 Convection heater unit 1
4- 9 NCPL-B007MRF0 Coupling 1
4-10 NFANMB003MRP0 Convection motor fan 1
4-11 LANGQB031MRP0 Convection motor angle 1
4-12 PPACGB013MRE0 Turntable motor packing 1
4-13 LBNDK0054WRE0 Heater mounting holder 2
4-14 NFANMB004MRP0 Convection fan 1
4-15 PHOK-B013MRF0 Latch hook 1
4-16 FANGTB003MRY0 Unit mounting plate 1
4-17 PFPF-B002MRE0 Heat protect L 1
4-18 PPIPFB002MRE0 Coller 1
4-19 PREFHB006MRP0 Heater cover L 1
4-20 PDUC-B083MRP0 Hood intake duct L 1
4-21 NFANPB005MRE0 Fan blade 1
4-22 HDECQB072MRF0 End cap holder L 1
4-23 FDUC-B065MRK0 Fan duct 1
4-24 LBSHC0037WRE0 Cord bushing 1
4-25 FDUC-B049MRK0 Exhaust duct 1
4-26 MLEVPB016MRF0 Open lever 1
4-27 PCUSGB030MRP0 Cushion 1
4-28 MCAMPB001MRF0 Damper cam 1
4-29 PCUSUB032MRP0 Damper cushion 1
4-30 PFPF-B001MRE0 Heat protect R 1
4-31 PFTA-B003MRP0 Damper plate 1
4-32 PREFHB004MRP0 Thermal cover R 1
4-33 HDECQB073MRF0 End cap holder R 1
4-34 PREFHB005MRP0 Thermal cover bottom 1
4-35 LSTPPB024MRF0 Door stopper 1
4-36 PCOVPB047MRP0 Oven lamp cover 1
4-37 PCOVPB050MRP0 Heat protect top sheet 1
4-38 PCUSGB027MRP0 Cushion 1
4-39 PDUC-B056MRF0A Hood exhaust duct 1
4-40 PDUC-B057MRP0 Top duct 1
4-41 PDUC-B058MRF0 Magnetron duct 1
4-42 PDUC-B060MRP0 Hood intake duct R 1
4-43 PFILWA035WRE0 Oven light screen 1
4-44 PFPF-B003MRE0 Heat protect top 1
4-45 LANGQB025MRP0 Noise filter angle 1
4-46 PCUSUB019MRP0 Exhaust cushion 1
4-47 PCUSUB020MRP0 Cushion 1
4-48 PCUSUB024MRP0 Cushion 1
4-49 PCUSUB033MRP0 Cushion 1
4-50 PCUSGB035MRP0 Cushion 1
4-51 PCUSUB047MRP0 Cushion 1
4-52 PCUSUB046MRP0 Cushion 1
4-53 PFPF-B005MRE0 Heat protect bottom 1
4-54 PFPF-B004MRE0 Heat protect rear 1
DOOR PARTS
5- 1 DDORFB109MRK0 Door panel assembly 1
5- 2 FCOV-B302MRK0 Door frame (VMOR205SS) 1
5- 2 FCOV-B303MRK0 Door frame (DMOR205SS) 1
5- 3 GCOVHB031MRF0 Choke cover 1
5- 4 LSTPPB025MRF0 Latch head 1
5- 5 MSPRTA046WRE0 Latch spring 1
5- 6 XCTSD40P08000 Screw : 4mm x 8mm 6
5- 7 LX-CZB019MRE0 Screw 3
5- 8 PCUSUB073MRP0 Door cushion 1
